GE V7769 Single Board Computer

GE V7769 Single Board  Computer

DESCRIPTION

GE’s V7768/V7769* are single board computers (SBCs) in a dual-slot, passively  cooled, VME Eurocard form factor.  The V7768* is a full featured Intel® CoreTM 2 Duo or Celeron® M-based SBC, and  the V7769* is a full featured Intel Core 2 Duo-based SBC. The V7768/V7769 utilize  the advanced technology of Intel’s 945GM chipset and the ICH7-M I/O Controller  Hub. The 945GM chipset runs on a 533 MHz front-side bus with the Celeron M  processor and a 667 MHz front-side bus with the Core 2 Duo processor.

Desktop Features of the V7769

• Up to 2.0 GByte DDR2 SDRAM (One SODIMM)

• SVGA port (front I/O)

• Dual Gigabit Ethernet (GbE) (front I/O)

• One RS232/422 COM port (front I/O)

• One RS232/422 COM support (rear I/O)

• Two USB 2.0 ports (front I/O)

• Four USB 2.0 support (rear I/O)

• Supports two SATA connections (rear I/O)

• One 2.5-in. SATA hard drive (optional for V7769 only)

• Dual SAS connector (front I/O on V7769 only)

• Real-Time clock/calendar

• Front panel reset switch

• PS/2 Keyboard/Mouse connection (front I/O)

• Onboard parallel connector

Embedded Features of the V7769

• Remote booting out the front panel only

• Up to 8 GByte of bootable CompactFlash (optional)

• PCI-X capable PMC site with VITA 35 P2 I/O (factory populated on V7768  and main board of V7769)

• VITA 1-1994 with byte swap

• 32 KByte NVRAM

• Software-selectable Watchdog Timer with reset

Intel 945GM Chipset

The V7768/V7769 incorporate the latest Intel chipset technology, the 945GM. The  Intel 945GM chipset is an optimized integrated graphics solution with up to a  667 MHz system bus. The chipset has a low power design, advanced power  management, supporting up to 2 GByte of DDR2 system memory. The 945GM is a  Memory Controller Hub (MCH) component, providing the processor interface,  system memory interface (DDR2 SDRAM) and SVGA port.

Key features for the 945GM:

• 533 MHz Processor system bus controller for the Celeron M

• 667 MHz Processor system bus controller for the Intel Core 2 Duo

• Up to 2 GByte DDR2 Memory via SODIMM

• High-speed DMI architecture interface for communication with the ICH7-M  (I/O controller)

The 945GM supports the Intel ICH7-M I/O controller hub. The ICH7-M supports  most of the high speed I/O interfaces of the V7768/V7769.

Key features for the ICH7-M:

• USB 2.0

• SATA

• IDE (Primary only)

• PCI

• PCI Express (PCIe)
