GE IC693MDL330 120/240 Volt AC Output - 2 Amp, 8 Point
❤ Add to collection

GE IC693MDL330 120/240 Volt AC Output - 2 Amp, 8 Point

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

This 2 amp AC output module has a catalog number with a D or later suffix (i.e.,

IC693MDL330D); previous versions (modules with a C or earlier suffix) were rated at 1 amp.

The 120/240 volt, 2 Amp AC Output module for the Series 90-30 Programmable Logic

Controller provides 8 output points in two isolated groups with four points in each group.

￥1666.00
￥1500.00
Weight：1.100KG
Quantity：
(Inventory: 10)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

This 2 amp AC output module has a catalog number with a D or later suffix (i.e.,

IC693MDL330D); previous versions (modules with a C or earlier suffix) were rated at 1 amp.

The 120/240 volt, 2 Amp AC Output module for the Series 90-30 Programmable Logic

Controller provides 8 output points in two isolated groups with four points in each group.

GE IC693MDL330 120/240 Volt AC Output - 2 Amp, 8 Point

120/240 Volt AC Output - 2 Amp, 8 Point
IC693MDL330
This 2 amp AC output module has a catalog number with a D or later suffix (i.e.,
IC693MDL330D); previous versions (modules with a C or earlier suffix) were rated at 1 amp.
The 120/240 volt, 2 Amp AC Output module for the Series 90-30 Programmable Logic
Controller provides 8 output points in two isolated groups with four points in each group. Each
group has a separate common associated with it. The two commons are not tied together
inside the module. This allows each group to be used on different phases of the AC supply, or
they can be powered from the same supply. Each group is protected with a 5 amp fuse for
each common, and an RC snubber is provided for each output to protect against transient
electrical noise on the power line. This module provides a high-degree of inrush current (10x
the rated current) which makes the outputs suitable for controlling a wide range of inductive
and incandescent loads. AC Power (DC power cannot be used) to operate loads connected to
outputs must be supplied by the user.
LED indicators which provide the ON/OFF status of each point are located at the top of the
module. There are two horizontal rows with eight green LEDs in each row and a red LED
centered between and to the right of the two rows. This module uses the upper eight LEDs,
labeled A1 through 8 for output status. The red “F” LED is a blown fuse indicator that turns
ON if any of the fuses should blow. An insert goes between the inside and outside surface of
the hinged door. The surface towards the inside of the module (when the hinged door is
closed) has circuit wiring information, and circuit identification information can be recorded
on the outside surface. The outside left edge of the insert is color-coded red to indicate a
high-voltage module. This module can be installed in any I/O slot of a 5 or 10-slot baseplate in
a Series 90-30 PLC system.
Table 7-4. Specifications for IC693MDL330
Rated Voltage 120/240 volts AC
Output Voltage Range 85 to 264 volts AC, 50/60 Hz
Outputs per Module 8 (two groups of four outputs each)
Isolation 1500 volts between field side and logic side
500 volts between each group
Output Current  2 amp maximum per point
4 amps maximum per group at 40  C (104  F)
Output Characteristics
Inrush Current 20 amps maximum for one cycle
Minimum Load Current 100 mA
Output Voltage Drop 1.5 volts maximum
Output Leakage Current 3 mA maximum at 120 volts AC
6 mA maximum at 240 volts AC
On Response Time 1 ms maximum
Off Response Time 1/2 cycle maximum
Power Consumption 160 mA (all outputs on) from 5 volt bus on backplane
Maximum load current is dependent upon ambient temperature as shown in graph on following page.
Refer to Appendix B for product standards and general specifications.


IC693MDL330 Output Module Field Wiring Information
The following figure provides wiring information for connecting user
supplied input devices and power source to the 120/240 volt AC output, 2 Amp
module.
