DESCRIPTION

The eTOP20B and eTOP21B are state-of-the-art HMI devices with touchscreen interface and 7.5”  TFT and STN color graphic displays. Support for 64K colors in the brilliant TFT display will increase  the realism of the images. The compact size and the VGA resolution make them an attractive solution  where space is a premium without compromising performance.

SPECIFICATION

• 7.5” TFT and STN color displays

• VGA (640x480 pixel) resolution

• 64K colors (eTOP20B only)

• Resistive touchscreen

• Connection to industrial bus systems and  Ethernet (requires optional plug-in modules)

• Compatible with video input module  (eTOP20B only)

• Large memory size (32MB Flash) on  removable media

Highlights

The eTOP HMI panels are part of the UniOP family of touchscreen products. All of the eTOP  products support the rich common functionality of the UniOP operator panels:

• Powerful and intuitive programming with  the UniOP Designer 6 software

• Support of more than 130 communication  drivers for industrial devices

• Optional modules for fieldbus systems  (Profibus DP, CANopen, DeviceNet,  Interbus) and Ethernet. Ethernet modules  allow connection to field devices as well  as programming the HMI from Designer.

• Dual-driver communication capability

• Vector graphic capabilities including the  support of multiple layers and object  transparency.

• Video input option (eTOP20B only)

• Display dynamic data in numerical, text,  bargraph and graphic image formats

• Data acquisition and trend presentation.  Trend data can be transferred to an host  computer using the Ethernet connection.

• Analog gauge objects

• Recipe data storage. Recipe data can be  transferred to an host computer using the  Ethernet connection.

• Multilanguage applications. The number  of runtime languages is limited only by the  available memory. All text information in  the application can be exported in Unicode  format for easier translation.

• Powerful macro editor to configure  touchscreen operation

• Alarms and historical alarm list. Alarm and event information can be printed or  transferred to an host computer using the  Ethernet connection.

• Eight level password protection.

• Report printing to serial printer. Reports  are freely configurable using Designer.

• Ethernet-based UniNet network to share  data between UniOP HMIs and to serve  data using UniNet OPC Server.

Environmental  Conditions

Operating temperature:0 to 45 °C

Storage temperature:-20 to +70 °C

Operating and storage:5 – 85 % RH non-condensing

Dimensions

Faceplate LxH:232x187 mm (9.14x7.63“)

Cutout AxB:221x176 mm (8.70x6.93“)

Cutout depth (type  0045):74 mm (2.92”)
