500CIM05 Product description

Product Overview:

The CIM05J152NC is an analog mixed-signal IC filter manufactured by ABB.

The main feature is a Ferrite Chip for high frequency EMI (electromagnetic interference) protection.

Main specifications:

Resistance value: 1500 ohms

Maximum DC current: 250 MA

Package size: 0402

Maximum frequency: 100 MHz (Note: Minimum frequency is also marked as 100 MHz, this may be an error or a feature of specific applications)

Height: 0.5mm

Length: 1 mm

Material: Ferrite

Mounting type: Surface Mount

Maximum operating temperature: 125 °C

Minimum operating temperature: -55 °C

Features and Benefits:

Perfect shape: Suitable for automatic installation, no directional requirements.

Excellent weldability and high heat resistance: high reliability for flow or reflow welding.

Monolithic inorganic material construction: provides high reliability.

Closed magnetic circuit configuration: Avoid crosstalk, suitable for high-density PCB (printed circuit board) use.

Application field:

Mainly used in computer, printer, video recorder, TV and mobile phone and other equipment high frequency EMI protection.

Recommended grounding mode:

According to the product information, the recommended grounding mode size is 0.45 to 0.55mm (length and width).

Certification and Compliance:

Compliance with RoHS (Restriction of the Use of Certain Hazardous Substances Directive) certification.

Reach Compliance Code compliant REACH Compliance Code compliant.

ECCN Code: EAR99 (US Export Control Classification Number).
