DESCRIPTION

Reid Vapor Pressure (RVP) is a vapor pressure  measurement of gasoline and its feedstocks that is  measured at a constant set of conditions which is  used to monitor the quantity of light compounds in  the gasoline. This measurement is used to reduce  the amount of pollution from light compounds such  as butane from escaping into the atmosphere and  also to make sure there are enough light compounds  to make sure car engines will start in cold  temperatures.

The RVP4500 series analyzers consist of several  models to cover various range requirements. The  ranges allow the analyzers to be used not only on  the final gasoline blending but also on the various  feedstocks to the gasoline blender. The RVP4550  offers a novel air saturation step that simulates the  manual air saturation step of the laboratory method  for the final gasoline blending operations. The  RVP4540 is the version that is used to measure the  vapor pressure in LPG and NGL streams.

• ASTM method D5482 (off-line mode)

– RVP4500 meets the requirements for this ASTM  method

• ASTM lab method D1267

– RVP4540 meets the requirements for this ASTM  method and measures vapor pressure of LPG or  LNG streams

• RVP 4510 Shale Oil

– RVP4510 measures RVP for demanding shale oil  process streams

RVP Trade in Program**

• 10% trade in allowance **

• 24/36 month factory warranty included

• 1st Year PM service included

• Factory Acceptance Testing included***

• Startup and commissioning with on-site  over the shoulder training included

• Priority Phone Support included

• Recommended spare parts list

Trade-in options

• Sample system upgrade

• Network upgrade

• Multi-year service agreements

STAR is the next generation of data system designed to unify  legacy instrumentation with the PGC5000 series.

• Complete optimization and plant monitoring.

• Windows based. Windows 10 for PC, OS 16 for Server

• Distributed, secure, and persisted Access Control List (ACL).

• Supports IPv4 and IPv6 and VistaNET ready devices.

• Allows remote upgrades, configuration and rebooting.

• Optional Star server saves minimum of 30 days of data from  PGC5000 (Version 4), PGC2000, RVP, and Multiwave.

• Import / Export trends, reprocessing of chromatograms,  archiving and trending of data values from multiple devices.
