GE SLN042 IC086SLN042-A Ethernet switch
GE SLN042 IC086SLN042-A Ethernet switch
DESCRIPTION
SLN042 series are unmanaged Ethernet switch with 4x10/100Base-T(x) and 2x100Base-F(x) With very compact size of housing, you can install easily. In addition, SLN042 can operate under harsh environment. o The extended operation temperature range is from -40 to 70 C.
Features
4x10/100Base-T(x) and 2x100Base-F(x)
Supports store and forward transmission
Supports flow control
Dual DC input 12-48VDC
Compact size for easily installation
Rigid IP-30 housing design
DIN-Rail and wall mounting enabled
Technology
Ethernet Standards:IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3x for Flow control
MAC Table:2048 MAC address
Processing:Store-and-Forward
LED Indicators
Power Indicator:Green: Power LED x2
Fault Indicator:Amber : Indicates PWR1 or PWR2 failure occurred
10/100Base-T(X) RJ45 Port Indicator:Green for port Link/Act. Amber for duplex indicator
Fiber Port LED:Green for port Link/Act.
Power
Input Power:Dual 12~48 VDC power inputs at 6-pin terminal block
Power Consumption(Typ.):7 Watts
Overload Current Protection:Present
Reverse Polarity Protection:Present on terminal block
Environmental
Storage Temperature:-40 to 85 C (-40 to 185 F)
Operating Temperature:-40 to 70 C (-40 to 158 F)
Operating Humidity:5% to 95% Non-condensing
