Manufacturers
ABB
Model(s)
ABB Advant Controller 31, ABB Advant OCS
Additional Information
GJR 525 0200 R0001
Estimated Shipping Size
Dimensions: 7.0" x 2.0" x 8.0"
(17.8 cm x 5.1 cm x 20.3 cm)
Weight: 0 lbs 7.1 oz (0.2kg )
Tariff Code: 8544429000
Country of Origin: Germany
Ships from Webster NY, USA
ABB GJR5250200R1 07SK90R1 Programming Cable - 5 meters
Basic information
Model number: ABB GJR5250200R1 07SK90R1 Programming Cable - 5 meters, where GJR5250200R1 is the detailed model number of the product, 07SK90R1 specifies the type of the programming cable, and 5 meters indicates that the cable is 5 metres long.
Origin: Generally produced in Sweden, but some sources indicate a German origin, which may vary from batch to batch or product line to product line.
Size and weight: Its dimensions are approximately 7.0 inches × 2.0 inches × 8.0 inches, i.e. 17.8cm × 5.1cm × 20.3cm, and it weighs approximately 0.2kg.
Functional Features
Device connection: The programming cable is mainly used to connect the ABB Advant Controller 31 and ABB Advant OCS and other devices with the programming interface, to achieve the communication between the device and the programming software, so that users can configure, monitor and troubleshoot the controller and other operations.
Signal transmission: It can transmit programming signals and data stably and accurately to ensure the smooth operation of programming. Its transmission rate and anti-interference ability and other performance indicators can meet the programming requirements of ABB related equipment to ensure the integrity and reliability of data transmission.
Technical Parameters
Interface type: one end is a 9-pin interface, used to connect the ABB Advant Controller 31 base unit or T200 communication processor 9-pin interface connector; the other end is adapted according to the interface type of the programming device, if the programming device is a 25-pin interface, you can use the 25-pin to 9-pin adapter for connection.
Cable length: 5 metres, which is sufficient to cover the distance between the device and the programming interface in general, but can be flexibly arranged according to the specific installation location and wiring requirements in practice.
Fields of application
Industrial automation control system programming: in the field of industrial automation, widely used in ABB Advant Controller 31 and ABB Advant OCS control system programming and debugging work. Engineers can use the programming cable to connect the programming device with the controller to write, download, upload and monitor the program online, so as to achieve the automation control and optimisation of the industrial production process.
Equipment Maintenance and Troubleshooting: When equipment malfunctions or system upgrades are required, technicians can use the programming cable to connect the equipment and programming tools to monitor and diagnose the operating status of the equipment, quickly locate the cause of the malfunction and carry out the corresponding repairs and programme updates to improve the efficiency of equipment maintenance and operational reliability.
FEATURES
• Process Station with integrated fieldbus capability
• 4 high-speed fieldbus lines
• Supports different fieldbus types, even simultaneously: PROFIBUS-DP, up to 12 MBd Modbus CAN Foundation Fieldbus H1 (with LD800 HSE)
• Easy engineering: fully integrated in Control Builder F
• One unified database for field devices shared by the control level and the Human System Interface (HSI)
• Module recognition with factory and operational parameters
• Comprehensive diagnostics for proactive maintenance
• Compact, rugged design
• Front panel connectors
• DIN Rail (C-rail) or wall mounting for easy installation
• Ambient temperature 0-60 °C (32-140 °F) with temperature monitoring
• EMC certification according to EN50082
• Certification: CE, NAMUR, CSA, UL, EN61000-6-2.
