GE IC693MAR590 Input output module
❤ Add to collection

GE IC693MAR590 Input output module

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

The 120 volt AC Input/Relay Output module for the Series 90-30 Programmable Logic

Controller provides 8 input points with one common power input terminal, and 8 normally-open

relay circuits in the same module. The input circuits are reactive (resistor/capacitor) inputs and

are arranged as one group of 8 inputs. The output points are arranged in two groups of four

points each. Each group has a common power output terminal.

￥18677.00
￥15675.00
Weight：1.100KG
Quantity：
(Inventory: 45)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

The 120 volt AC Input/Relay Output module for the Series 90-30 Programmable Logic

Controller provides 8 input points with one common power input terminal, and 8 normally-open

relay circuits in the same module. The input circuits are reactive (resistor/capacitor) inputs and

are arranged as one group of 8 inputs. The output points are arranged in two groups of four

points each. Each group has a common power output terminal.

GE IC693MAR590 Input output module

120 Volt AC Input, Relay Output, 8 Inputs/8 Outputs
IC693MAR590
The 120 volt AC Input/Relay Output module for the Series 90-30 Programmable Logic
Controller provides 8 input points with one common power input terminal, and 8 normally-open
relay circuits in the same module. The input circuits are reactive (resistor/capacitor) inputs and
are arranged as one group of 8 inputs. The output points are arranged in two groups of four
points each. Each group has a common power output terminal.
Input characteristics are compatible with a wide range of user-supplied devices, such as:
pushbuttons, limit switches, and electronic proximity switches. Current through an input results
in a logic 1 in the input status table (%I). Power to operate the field devices must be supplied
by the user. This module’s input section requires an AC power source, it cannot be used with a
DC power source.
The normally-open relay circuits are used for controlling output loads provided by the user.
The output switching capacity of each output is 2 amps. The relay outputs can control a wide
range of user-supplied load devices, such as: motor starters, solenoids, and indicators. Power
for the internal relay circuits is provided by the +24 volt DC bus on the backplane. The user
must supply the AC or DC power to operate field devices. There are no fuses on this module.
LED indicators which provide the ON/OFF status of each point are located at the top of the
module. The LEDs are arranged in two horizontal rows with eight green LEDs in each row.
The top row is labeled A1 through 8 (input points 1 through 8) and the bottom row is is labeled
B1 through B8 (relay output points 1 through 8). An insert goes between the inside and outside
surface of the hinged door. The surface towards the inside of the module (when the hinged door
is closed) has circuit wiring information, and circuit identification information can be recorded
on the outside surface. The outside left edge of the insert is color-coded red to indicate a
high-voltage module.
This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC
system.


Table 8-1. Specifications for IC693MAR590
Inputs
Rated Voltage 120 volts AC
Input Voltage range 0 to 132 volts AC
Inputs per Module 8 (one group of eight inputs)
Isolation 1500 volts RMS between field and logic side
500 volts RMS between inputs
Input Current 12 mA (typical) at rated voltage
Input Characteristics
On-State Voltage 74 to 132 volts AC
Off-State Voltage 0 to 20 volts AC
On-State Current 6 mA (minimum)
Off-State Current 2.2 mA (maximum)
On Response Time 30 ms typical
Off Response Time 45 ms typical
Outputs
Rated Voltage 24 VDC, 120/240 VAC
Operating Voltage 5 to 30 volts DC
5 to 250 volts AC, 50/60 Hz
Outputs per Module 8 (two groups of four outputs each)
Isolation 1500 volts RMS between field and logic side
500 volts RMS between groups
Maximum Load  2 amps maximum per output
4 amps maximum per common
Minimum Load 10 mA
Maximum Inrush 5 amps
On Response Time 15 ms maximum
Off Response Time 15 ms maximum
Internal Power Consumption 80 mA (all I/O on) from +5V backplane bus
70 mA (all outputs on) from relay +24V backplane bus
Maximum load current is dependent on operating voltage as shown in the following table.
Refer to Appendix B for product standards and general specifications.
Table 8-2. Load Current Limitations for IC693MAR590
Operating Maximum Current for Load Type Typical Contact Life
Voltage Resistive Lamp or Solenoid  (number of Operations)
240 VAC, 120 VAC, 24 VDC 2 amps .6 amps 200,000
240 VAC, 120 VAC, 24 VDC 1 amp .3 amps 400,000
240 VAC, 120 VAC, 24 VDC .5 amps .1 amp 800,000
