UniOP eTOP407 HMI device

UniOP eTOP407  HMI device

DESCRIPTION

The UniOP eTOP Series 400 HMI products combine state-of-the-art features and top performance  with an oustanding design. They are the ideal choice for all demanding HMI applications including  factory and building automation.  The eTOP407 features a bright 7” TFT widescreen (16:9) display with LED backlight.  The JMobile software offers full vector graphic capabilities and plenty of connectivity options.

SPECIFICATION

• 7” TFT color display, LED backlight

• 800x480 pixel (WVGA) resolution, 64K colors

• Advanced vector graphics and client-server  connectivity powered by JMobile

• Resistive touchscreen

• 10/100 Ethernet interface

• USB interface

• Connection to bus systems using optional  plug-in modules

• Slim design. Mounting depth less than 50mm

Highlights

The eTOP Series 400 HMI panels have been designed to run the JMobile software.

• JMobile runtime included. Full  compatibility with JMobile Studio.

• Full vector graphic support. Native support  of SVG graphic objects. Trasparency and  alpha blending.

• Full object dynamics: control visibility and  transparency, move, resize, rotate any  object on screen. Change properties of  basic and complex objects.

• TrueType fonts

• Multilanguage applications. Easily create  and manage your applications in multiple  languages to meet global requirements.  Far East languages are supported. Tools  available in JMobile Studio support easy  third-party translations and help reducing  development and maintenance costs of  the application

• Data display in numerical, text, bargraph,  analog gauges and graphic image  formats.

• Rich set of state-of-the-art HMI features:  data acquisition, alarm handling,  scheduler and timed actions (daily and  weekly schedulers, exception dates),  recipes, users and passwords, e-mail and  RSS feeds, rotating menus

• Includes support for a wide range of  communication drivers for Factory and  Building Automation systems.

• Multiple drivers communication capability.

• Remote monitoring and control. ClientServer functionality. Mobile clients  supported.

• Off-line and On-line simulation with  JMobile Studio.

• Powerful scripting language for  automating HMI applications. Script  debugging improves efficiency in  application development.

• Rich gallery of symbols and objects

• Project templates

• Optional plug-in modules for fieldbus  systems, networks and controllers.  Compatible with TCM and SCM modules.

Technical Data

Power supply voltage：24 Vdc (18 to 30 Vdc)

Current consumption：0.7A at 24Vdc(max.)

Weight：Approx 1.0 Kg

Operating temperature：0 to 50 °C (vertical  installationmounting)

Storage temperature：-20 to +70 °C

Operating and storage：5 – 85 % relative humidity,

humidity：non-condensing
