Home >> GE >> GE ZA06B-0219-B200 Servo Amplifiers
Current position：

Brand
GE ZA06B-0219-B200 Servo Amplifiers
❤ Add to collection

GE ZA06B-0219-B200 Servo Amplifiers

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

Ordering Information

Motor Model α2/6000HVis α4/5000HVis α8/6000HVis

Motor Part Number ZA06B-0219-B200 ZA06B-0216-B200 ZA06B-0233-B200

Motor/Brake Part Number ZA06B-0219-B500 ZA06B-0216-B500 ZA06B-0233-B500

Beta Amplifier Model βSVM1-10HVi βSVM1-10HVi βSVM1-40HVi

Beta Amplifier Part Number ZA06B-6131-H001 ZA06B-6131-H001 ZA06B-6131-H003

Beta Amplifier Fan Kit (Note1) n/a n/a ZA06B-6134-K002

Beta Amplifier Kit IC800BIHV010 IC800BIHV010 IC800BIHV040

Alpha Amplifier Model αSVM1-10HVi αSVM1-10HVi αSVM1-40HVi

Alpha Amplifier Part Number ZA06B-6127-H102 ZA06B-6127-H102 ZA06B-6127-H104

Alpha Amplifier Kit IC800AIHV010 IC800AIHV010 IC800AIHV040

￥15000.00
￥15000.00
Weight：3.550KG
Quantity：
(Inventory: 50)
Consultation
Accessories
  • ABB-Binary I/O m
    Original ：￥15774.00
    With a price ：￥15774    		 Quantity
  • ABB-Optical star
    Original ：￥9993.00
    With a price ：￥9993    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

Ordering Information

Motor Model α2/6000HVis α4/5000HVis α8/6000HVis

Motor Part Number ZA06B-0219-B200 ZA06B-0216-B200 ZA06B-0233-B200

Motor/Brake Part Number ZA06B-0219-B500 ZA06B-0216-B500 ZA06B-0233-B500

Beta Amplifier Model βSVM1-10HVi βSVM1-10HVi βSVM1-40HVi

Beta Amplifier Part Number ZA06B-6131-H001 ZA06B-6131-H001 ZA06B-6131-H003

Beta Amplifier Fan Kit (Note1) n/a n/a ZA06B-6134-K002

Beta Amplifier Kit IC800BIHV010 IC800BIHV010 IC800BIHV040

Alpha Amplifier Model αSVM1-10HVi αSVM1-10HVi αSVM1-40HVi

Alpha Amplifier Part Number ZA06B-6127-H102 ZA06B-6127-H102 ZA06B-6127-H104

Alpha Amplifier Kit IC800AIHV010 IC800AIHV010 IC800AIHV040



GE ZA06B-0219-B200 Servo Amplifiers

Servo Amplifiers Motion Control Systems
αHVi Series Amplifier and Motor
Ordering Information
Motor Model α2/6000HVis α4/5000HVis α8/6000HVis
Motor Part Number ZA06B-0219-B200 ZA06B-0216-B200 ZA06B-0233-B200
Motor/Brake Part Number ZA06B-0219-B500 ZA06B-0216-B500 ZA06B-0233-B500
Beta Amplifier Model βSVM1-10HVi βSVM1-10HVi βSVM1-40HVi
Beta Amplifier Part Number ZA06B-6131-H001 ZA06B-6131-H001 ZA06B-6131-H003
Beta Amplifier Fan Kit (Note1) n/a n/a ZA06B-6134-K002
Beta Amplifier Kit IC800BIHV010 IC800BIHV010 IC800BIHV040
Alpha Amplifier Model αSVM1-10HVi αSVM1-10HVi αSVM1-40HVi
Alpha Amplifier Part Number ZA06B-6127-H102 ZA06B-6127-H102 ZA06B-6127-H104
Alpha Amplifier Kit IC800AIHV010 IC800AIHV010 IC800AIHV040
Cables α2/6000HVis α4/5000HVi α8/6000HVis
Power Cable 7 M CP2I-0WPB-0070-AZ CP2I-0WPB-0070-AZ CP3I-0WPB-0070-AZ
14 M CP2I-0WPB-0140-AZ CP2I-0WPB-0140-AZ CP3I-0WPB-0140-AZ
Power Cable 7 M CP2I-0WEB-0070-AZ CP2I-0WEB-0070-AZ CP3I-0WEB-0070-AZ
(Shielded) 14 M CP2I-0WEB-0140-AZ CP2I-0WEB-0140-AZ CP3I-0WEB-0140-AZ
Feedback Cable 7 M CFDA-7WPB-0070-AZ CFDA-7WPB-0070-AZ CFDA-7WPB-0070-AZ
(Right Angle) 14 M CFDA-7WPB-0140-AZ CFDA-7WPB-0140-AZ CFDA-7WPB-0140-AZ
Feedback Cable 7 M CFDA-0WPB-0070-AZ CFDA-0WPB-0070-AZ CFDA-0WPB-0070-AZ
(Straight) 14 M CFDA-0WPB-0140-AZ CFDA-0WPB-0140-AZ CFDA-0WPB-0140-AZ
Brake Power Cable 7 M Integrated with power cable Integrated with power cable CB4N-0WPM-0070-AZ
14 M Integrated with power cable Integrated with power cable CB4N-0WPM-0140-AZ
PSM Interface Cable (External Battery) 200 mm Z44C746453-001 Z44C746453-001 Z44C746453-001
PSM Interface Cable (Built-in or No Battery) 200 mm Z44C746453-002 Z44C746453-002 Z44C746453-002
Fiber Optic Command Cable 15 CM ZA66L-6001-0023#L150R0
30 CM ZA66L-6001-0023#L300R0
1 M ZA66L-6001-0023#L1R003
2 M ZA66L-6001-0023#L2R003
3 M ZA66L-6001-0023#L3R003
Fiber Optic Cable (Sheathed) 1 M ZA66L-6001-0026#L1R003
3 M ZA66L-6001-0026#L3R003
5 M ZA66L-6001-0026#L5R003
10 M ZA66L-6001-0026#L10R03
20 M ZA66L-6001-0026#L20R03
30 M ZA66L-6001-0026#L30R03
50 M ZA66L-6001-0026#L50R03
100 M ZA66L-6001-0026#L100R3
Connector Kits α2/6000HVis α4/5000HVi α8/6000HVis
Encoder Feedback Connector (JF1) ZA06B-6073-K214 ZA06B-6073-K214 ZA06B-6073-K214
CXA2A/B Jumper Connector (2 Req) ZA06B-6110-K210 ZA06B-6110-K210 ZA06B-6110-K210
CZ2 Motor Power Output Connector ZA06B-6110-K203#ZZM ZA06B-6110-K203#ZZM ZA06B-6110-K203#ZZM
Motor Half Keys Z44A730465-001 Z44A730465-016 Z44A730465-002
Motor Feedback Connector Kit 90 Deg ZA06B-6114-K204#E ZA06B-6114-K204#E ZA06B-6114-K204#E
Straight ZA06B-6114-K204#S ZA06B-6114-K204#S ZA06B-6114-K204#S
Motor Power/Brake Connector Kit 90 Deg ZA06B-6114-K220#E ZA06B-6114-K220#E n/a
Straight ZA06B-6114-K220#S ZA06B-6114-K220#S n/a
Motor Power Connector Kit 90 Deg n/a n/a Z44A730464-G18
Straight n/a n/a Z44A730464-G17
Motor Brake Connector Kit 90 Deg n/a n/a ZA06B-6114-K213#E
Straight n/a n/a ZA06B-6114-K213#S
Accessories α2/6000HVis α4/5000HVi α8/6000HVis
DC Link Bus Bars Z44A718031-G05 Z44A718031-G05 Z44A718031-G05
Spare Amplifier Control Power Fuse ZA06B-6073-K250 ZA06B-6073-K250 ZA06B-6073-K250
Encoder Battery Back-up (Multi-Axis Panel Mounted Kit) (Note 2) IC800ABK001 IC800ABK001 IC800ABK001
Encoder Battery Back-up (Single-Axis Built-in) (Note 2) IC800ABK002 IC800ABK002 IC800ABK002
1) Separate user installed cooling fan is only required for the βSVM1-40HVi amplifier. This fan kit is included in the IC800BIHV040 amplifier kit but must be separately ordered when the ZA06B-6131-H003
amplifier is ordered.
2) Contents of encoder battery kits is shown on page 78


Servo Amplifiers Motion Control Systems
αHVi Series Amplifier and Motor
Ordering Information (continued)
Motor Model α30/4000HVis α40/4000HVis
Motor Part Number ZA06B-0269-B200 ZA06B-0273-B200
Motor/Brake Part Number ZA06B-0269-B500 ZA06B-0273-B500
Alpha Amplifier Model αSVM1-80HVi αSVM1-80HVi
Alpha Amplifier Part Number ZA06B-6127-H105 ZA06B-6127-H105
Alpha Amplifier Kit IC800AIHV080 IC800AIHV080
Dynamic Braking Module n/a n/a
Cables α30/4000HVis α40/4000HVis
Power Cable 7 M CP4I-0WPB-0070-AZ CP4I-0WPB-0070-AZ
14 M CP4I-0WPB-0140-AZ CP4I-0WPB-0140-AZ
Power Cable 7 M CP4I-0WEB-0070-AZ CP4I-0WEB-0070-AZ
(Shielded) 14 M CP4I-0WEB-0140-AZ CP4I-0WEB-0140-AZ
Feedback Cable 7 M CFDA-7WPB-0070-AZ CFDA-7WPB-0070-AZ
(Right Angle) 14 M CFDA-7WPB-0140-AZ CFDA-7WPB-0140-AZ
Feedback Cable 7 M CFDA-0WPB-0070-AZ CFDA-0WPB-0070-AZ
(Straight) 14 M CFDA-0WPB-0140-AZ CFDA-0WPB-0140-AZ
Brake Power Cable 7 M CB4N-0WPM-0070-AZ CB4N-0WPM-0070-AZ
14 M CB4N-0WPM-0140-AZ CB4N-0WPM-0140-AZ
Fan Cable 7 M n/a n/a
14 M n/a n/a
PSM Interface Cable (External Battery) 200 mm Z44C746453-001 Z44C746453-001
PSM Interface Cable (Built-in or No Battery) 200 mm Z44C746453-002 Z44C746453-002
Fiber Optic Command Cable 15 CM ZA66L-6001-0023#L150R0
30 CM ZA66L-6001-0023#L300R0
1 M ZA66L-6001-0023#L1R003
2 M ZA66L-6001-0023#L2R003
3 M ZA66L-6001-0023#L3R003
Fiber Optic Cable (Sheathed) 1 M ZA66L-6001-0026#L1R003
3 M ZA66L-6001-0026#L3R003
5 M ZA66L-6001-0026#L5R003
10 M ZA66L-6001-0026#L10R03
20 M ZA66L-6001-0026#L20R03
30 M ZA66L-6001-0026#L30R03
50 M ZA66L-6001-0026#L50R03
100 M ZA66L-6001-0026#L100R3
Connector Kits α30/4000HVis α40/4000HVis
Encoder Feedback Connector (JF1) ZA06B-6073-K214 ZA06B-6073-K214
CXA2A/B Jumper Connector (2 Req) ZA06B-6110-K210 ZA06B-6110-K210
CZ2 Motor Power Output Connector ZA06B-6110-K203#ZZM ZA06B-6110-K203#ZZM
CX8/CX9 DB Module Interface Connector Kit n/a n/a
CX1A/B 180HVi Amplifier Control Power n/a n/a
Motor Half Keys Z44A730465-003 Z44A730465-003
Motor Feedback Connector Kit 90 Deg ZA06B-6114-K204#E ZA06B-6114-K204#E
Straight ZA06B-6114-K204#S ZA06B-6114-K204#S
Motor Power Connector Kit 90 Deg Z44A730464-G20 Z44A730464-G20
Straight Z44A730464-G19 Z44A730464-G19
Motor Brake Connector Kit 90 Deg ZA06B-6114-K213#E ZA06B-6114-K213#E
Straight ZA06B-6114-K213#S ZA06B-6114-K213#S
Motor Fan Connector Kit 90 Deg n/a n/a
Straight n/a n/a
Accessories α30/4000HVis α40/4000HVis
DC Link Bus Bars Z44A718031-G05 Z44A718031-G05
Spare Amplifier Control Power Fuse ZA06B-6073-K250 ZA06B-6073-K250
Encoder Battery Back-up (Panel Mounted Kit) (Note 1) IC800ABK001 IC800ABK001
Encoder Battery Back-up (Built-in) (Note 1) IC800ABK002 IC800ABK002
