Unit is equipped with dual channels (optional RS232C, RS485).

2. Data input/output can be completed with simple sequence commands.

When reading data from SCU, use PLC application command [READ], and when writing data to SCU, use application command

Execute with [WRT]. Post processing is run by shared memory between CPU UNIT and SCU, so complex programs

No need to create.

3. SCU Units have added RS-485 network functionality to the previously used N series SDU modules,

Expanded its usefulness.

4. The network can be constructed using RS232C communication and RS485 communication.

Can input/output data with RS232 devices:

Can be connected to IDX displays, instruments, barcode readers, printers, etc. for data input/output

Data can be input/output through the network with h RS485 device:

Connect to temperature controller, network frequency converter, and network servo through the network

5. Can be installed indefinitely in the PLC slot, transmitting 500 bytes at a time.

6. The available transmission codes can also be ASCII or HEX (Binary).

7. During communication, the terminal code can be freely set to PLC Ryder commands.

1 Specification and product configuration

NX70 PLC

SCU unit

(NX70-SCU)

one

Interface RS232 C/RS485 2 ports

transmission speed

Selected by DSW1 and DSW2

1) When using RS232C: 300/600/1200/4800/9600/19200/38400 bps

2) When using RS485: 4800/9600/19200/38400 bps

Communication Half Duplex

Synchronous Asynchronous (START-STOP)

When using RS232C transmission distance: 15 meters (MAX), when using RS485: 1.2 kilometers

Transfer code ASCII or HEX (Binary)

Data transmission format

STOP bit 1-bit/2-bit

Peritiyu/None (even/odd)

Data length of 7 bits/8 bits

The data transmission order starts from bit 0 and is sent in character units

Message unit for sending unit to terminal code (variable length)

Maximum message length MAX.500 Byte/frame (including end-to-end code)

CPU Unity

Interface

Shared memory method

For the. N series: The application commands F150 (READ) and F151 (WRT) can be read and written

For the. NPlus series: the application commands "READ" and "WHITE" can read and write

I/O allocation input 16 points, output 16 points

Terminal code settings: ① Choose from the three types of cr ② cr+LF ③ ETX, or set any code in shared memory

Initial code Initial code Yes/No

Other special control terminal code Cut transmission and reception mode (controlled by Siquens command) for easy printer output.

Soft reset (controlled by Siquens command)
