GE IC693MDL632 125 Volt DC Positive/Negative Logic Input, 8 Point
❤ Add to collection

GE IC693MDL632 125 Volt DC Positive/Negative Logic Input, 8 Point

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

This 125 volt DC Positive/Negative Logic Input module provides 8 input points in two isolated

groups with four points in each group. Each group has a separate common associated with it

(the two commons are not tied together inside the module).


￥3000.00
￥2500.00
Weight：1.100KG
Quantity：
(Inventory: 22)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

This 125 volt DC Positive/Negative Logic Input module provides 8 input points in two isolated

groups with four points in each group. Each group has a separate common associated with it

(the two commons are not tied together inside the module).


GE IC693MDL632 125 Volt DC Positive/Negative Logic Input, 8 Point

125 Volt DC Positive/Negative Logic Input, 8 Point
IC693MDL632
This 125 volt DC Positive/Negative Logic Input module provides 8 input points in two isolated
groups with four points in each group. Each group has a separate common associated with it
(the two commons are not tied together inside the module). The input module is designed to
have either positive logic characteristics in that it sinks current from the input devices to the
user common or negative power bus, or negative logic characteristics in that it sources current
through the input devices to the user common or positive power bus. The input device is
connected between the power bus and the module input. Current into an input point results in a
logic 1 in the input status table (%I). Input characteristics are compatible with a wide range of
input devices, such as pushbuttons, limit switches, and electronic proximity switches. Power
to operate field devices must be supplied by the user.
LED indicators which provide the ON/OFF status of each point are located at the top of the
module. This LED block has two horizontal rows with eight green LEDs in each row. This
module uses the top row labeled A1 through 8 (points 1 through 8). An insert goes between
the inside and outside surface of the hinged door. The surface towards the inside of the module
(when the hinged door is closed) has circuit wiring information, and circuit identification
information can be recorded on the outside surface. The outside left edge of the insert is
color-coded red to indicate a high-voltage module.

This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC

Table 6-5. Specifications for IC693MDL632
Rated Voltage 125 volts DC (Positive or Negative Logic)
Input Voltage Range 0 to +150 volts DC
Inputs per Module 8 (two groups of four inputs)
Isolation 1500 volts between field side and logic side
500 volts between groups
Input Current 4.5 mA typical
Input Characteristics
On-state Voltage 90 to 150 volts DC
Off-state Voltage 0 to 30 volts DC
On-state Current 3.1 mA
Off-state Current 1.1 mA maximum
On response Time 7 ms typical
Off response Time 7 ms typical
Internal Power Consumption 40 mA from the 5 volt bus on the backplane
36 mA (typical) from user input supply (all inputs
ON)

Number of inputs on is dependent upon ambient temperature as shown in figure 6–11.
Refer to Appendix B for product standards and general specifications.
IC693MDL632 Input Module Field Wiring Information
The following figure provides wiring information for connecting user supplied input devices
and power source to the 125 volt DC positive/negative logic input module. The negative logic
connections are shown in dashed lines.
