EMERSON PrPMC6001 PCI Mezzanine Card

EMERSON PrPMC6001 PCI Mezzanine Card

DESCRIPTION

The Emerson PrPMC6001 PCI mezzanine card (PMC) is a perfect fit for embedded applications requiring low power and high performance with PowerPC® architecture. The Marvel Discovery III system controller, with its feature-rich functionality, adds performance value to the end application. The PrPMC6001’s ability to support hard real-time applications using VxWorks RTOSs and cost-conscious applications with the Linux OS will enable this product to be used in wide variety of applications

PCI Mezzanine Card products from Emerson Network Power provide the flexibility to easily expand I/O functionality and performance within an embedded computer system. Our PMC building blocks offer a range of options that help optimize your application to meet your customer’s requirements.

FEAYURES

·MPC7448 PowerPC G4 processor running at up to 1.4 GHz

·Highly integrated Marvell Discovery III system controller

·133 MHz front side bus

·Fully compliant to the VITA-32 Processor PMC and VITA-39 PCI-X Auxiliary standards

·PTMC compliant P4 connector

·Memory configurations possible up to 1GB with ECC support

·1MB L2 cache

·Supporting MontaVista CGE3.1, PE3.1 and kernel.org 2.6.10

·VxWorks support for hard realtime applications and supporting VxWorks 5.5 and 5.5.1

·4MB of boot flash and 128MB of user flash

·128-bit wide AltiVec technology support

·64-bit, 66-133 MHz PCI-X bus interface

·Configurable monarch/nonmonarch mode

·Dual independent Gigabit Ethernet (GbE) interfaces. 2nd GbE interface has optional SerDes support for fiber transceiver

·Dual serial interfaces

·Optional JTAG support for debugging ° °

Specifications

ASYNCHRONOUS SERIAL PORT

Controller: Discovery III PHB UART

Number of Ports: Two

Configuration: RS-232

Async Baud Rate, b/s max.: 115Kb/s raw via 12.5 MHz clock

Routing: Pn4 (PTMC compliant)

IEEE P1386.1 INTERFACE

Connectors: Pn1, Pn2, Pn3, Pn4 (Pn4 compliant to PTMC standard)

Address/Data: 32-bit address/64-bit data

PCI Bus Clock: PCI/PCI-X @ 33, 66, 133 MHz

Signaling: 3.3/5V VIO (PCI), 3.3V VIO (PCI-X)

Power: +3.3V, +5V

Height: 10mm standoff (1GB variant violates CMC height mechanicals, additional 5 mm spacing suggested)

Module Type: single-wide, standard length

Software

MontaVista

CGE3.1 PE3.1

Kernel.org 2.6.10
