GE CP238TA Multi-Purpose PMC Expansion Card

GE CP238TA Multi-Purpose PMC Expansion Card

DESCRIPTION

The GE CP238TA Multi-Purpose PMC Expansion Card is a versatile and high-performance card designed for various applications. With its compact size and flexible interface, it provides seamless integration and expansion capabilities for compatible systems. The card offers a range of parameters that can be configured to meet specific requirements. It is suitable for a wide range of applications, including but not limited to industrial automation, data acquisition, and signal processing.

Product Features

Stability: As a GE brand product, the CP238TA expansion card is known for its stability and is suitable for a variety of demanding industrial environments.

Versatility: As a PMC expansion card, the CP238TA is able to provide a variety of functional extensions to meet different application requirements.

Compatibility: Compatible with cPCI systems, it can be easily integrated into existing systems for seamless connectivity.

Technical parameters

Specification: 213296 (unit may be millimetre, you need to refer to the official data)

Voltage: 24V

Weight: 1.3kg

Output frequency: 65 (specific units need to refer to official data)

System environment: normal

Whether imported: Yes

Functional Characteristics:

Modular Design: The modular nature of the CP238TA allows for easy integration and expansion within existing CompactPCI systems.

Hot-Swap Capability: With its hot-swap registers, the card can be safely removed or inserted without disrupting system operations.

Versatility: The card’s ability to operate at different bit widths and frequencies makes it suitable for a wide range of applications.

Application Fields:

Power Generation: The CP238TA finds extensive use in power plants, where it controls and monitors the combustion process and generator output in gas turbine generator sets.

Industrial Automation: In industrial settings, the card can be utilized for power generation and distribution, controlling industrial processes and energy production.

Regional Heating: It is also suitable for use in systems that supply hot water and heating, controlling the combustion process and hot water output.

Emergency Power: Gas turbine generator sets, equipped with the CP238TA, can serve as reliable emergency power sources during power outages.

Energy Stations: In energy stations, the card plays a crucial role in adjusting the output of various energy-generating systems.

Specifications:

PMC Slots: The CP238TA offers two PMC slots, each capable of operating at 32 or 64-bit width and with frequencies of either 33 MHz or 66 MHz.

Interfaces: It provides a complete set of hot-swap registers for蓝光 control and includes a 10/100/1000BaseTX Ethernet port on the front panel for seamless network connectivity.

Bus Architecture: The card supports asynchronous operation of the primary and secondary PCI buses, ensuring efficient data transfer and processing.
