GE IC693MDL732 12/24 Volt DC Positive Logic Output - 0.5 Amp, 8 Point
❤ Add to collection

GE IC693MDL732 12/24 Volt DC Positive Logic Output - 0.5 Amp, 8 Point

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

This 12/24 volt DC Positive Logic 0.5 Amp Output module for the Series 90-30 Programmable

Logic Controller provides 8 output points in one group of eight with a common power output

terminal.

￥6000.00
￥6000.00
Weight：3.300KG
Quantity：
(Inventory: 50)
Consultation
Accessories
  • GE FANUC IC698AC
    Original ：￥500.00
    With a price ：￥500    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

This 12/24 volt DC Positive Logic 0.5 Amp Output module for the Series 90-30 Programmable

Logic Controller provides 8 output points in one group of eight with a common power output

terminal.

GE IC693MDL732 12/24 Volt DC Positive Logic Output - 0.5 Amp, 8 Point

12/24 Volt DC Positive Logic Output - 0.5 Amp, 8 Point
IC693MDL732
This 12/24 volt DC Positive Logic 0.5 Amp Output module for the Series 90-30 Programmable
Logic Controller provides 8 output points in one group of eight with a common power output
terminal. This output module is designed to have positive logic characteristics in that it
sources current to the loads from the user common or positive power bus. The output device is
connected between the negative power bus and the module output. The output characteristics
are compatible with a wide range of user-supplied load devices, such as: motor starters,
solenoids, and indicators. Power to operate the field devices must be supplied by the user.
LED indicators which provide the ON/OFF status of each point are located at the top of the
module. This LED block has two horizontal rows with eight green LEDs in each row with the
top row labeled A1 through 8 (points 1 through 8) and the bottom row labeled B1 through 8
(points 9 through 16). An insert goes between the inside and outside surface of the hinged
door. The surface towards the inside of the module (when the hinged door is closed) has
circuit wiring information, and circuit identification information can be recorded on the outside
surface. The outside left edge of the insert is color-coded blue to indicate a low-voltage
module. There are no fuses on this module.
This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC
system.


Table 7-9. Specifications for IC693MDL732
Rated Voltage 12/24 volts DC
Output Voltage Range 12 to 24 volts DC (+20%, –15%)
Outputs per Module 8 (one group of eight outputs)
Isolation 1500 volts between field side and logic side
Output Current 0.5 amps maximum per point
2 amps maximum per common
Output Characteristics
Inrush Current 4.78 amps for 10 ms
Output Voltage Drop 1 volt maximum
Off-state Leakage 1 mA maximum
On Response Time 2 ms maximum
Off Response Time 2 ms maximum
Power Consumption 50 mA (all outputs on) from 5 volt bus on backplane
Refer to Appendix B for product standards and general specifications.
