GE IS200WROGH1A High-Performance Programmable Logic Controller Module

GE IS200WROGH1A High-Performance Programmable Logic Controller Module

Processor Speed:40 MHz Memory Size:512 KB RAM, 2 MB Flash Communication Interfaces:EtherNet/IP, DeviceNet Power Consumption:15 W Operating Temperature:-20"C to +70"C The GE IS200WROGH1A PLC Control Board integrates advanced microprocessors for seamless operation in complex industrial environments. Its robust design ensures consistent performance under varying conditions. Equipped with an impressive memory capacity, this board supports extensive programming and data management, facilitating sophisticated control applications. Featuring versatile communication interfaces, the IS200WROGH1A seamlessly connects with a wide range of industrial devices, enhancing system integration capabilities.

 With its efficient power consumption and wide operating temperature range, this board is suitable for diverse industrial settings, ensuring reliable operation in extreme conditions. Built with durability in mind, the IS200WROGH1A is constructed from high-grade materials, providing long-lasting performance and maintenance-free operation. The GE IS200WROGH1A is a high-performance programmable logic controller (PLC) module designed for industrial automation systems, offering advanced control and monitoring capabilities.

OTHER INFORMATION

• Available with either the 1.1 GHz, 1.6 GHz or 1.8 GHz  Pentium® M processor

• 1.4 GHz Pentium M processor coming soon

• Up to 2 Mbyte of advanced L2 cache

• Up to 1.5 Gbyte DDR SDRAM

• Up to 2 Gbyte bootable CompactFlash on secondary IDE (see  ordering options)

• Internal SVGA and DVI controller

• Serial ATA support through P2 rear I/O

• 400 MHz system bus via Intel® 855GME chipset

• Ethernet controller supporting 10BaseT and 100BaseTX  through the front panel

• Gigabit Ethernet controller supporting 10BaseT, 100BaseTX  and 1000BaseT interface with optional VITA 31.1 support

• Four asynchronous 16550 compatible serial ports

• Four Universal Serial Bus (USB) Rev. 2.0 connections, two on  the front panel and two rear I/O

• PMC expansion site (PCI-X, 66 MHz)

• 32 Kbyte of nonvolatile SRAM

• Operating system support for Windows® XP, Windows 2000,  VxWorks®, QNX® , LynxOS® and Linux

Features

▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user  memory.

▪ Provides access to bulk memory via reference table %W.

▪ Configurable data and program memory.

▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

▪ Supports auto-located Symbolic Variables that can use any amount of user memory.

▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for  analog %AI and %AQ.

▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a  list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

▪ Supports all VME modules supported by Series 90-70.

▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server  and FTP connections.

▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.

▪ Test Edit mode allows you to easily test modifications to a running program.

▪ Bit-in-word referencing.

▪ Battery-backed calendar clock.

▪ In-system upgradeable firmware.

▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232  Ethernet station manager serial port.

▪ The embedded Ethernet interface provides:

- Data exchange using Ethernet Global Data (EGD)

- TCP/IP communication services using SRTP

- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client

- Full programming and configuration services

- Comprehensive station management and diagnostic tools

- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

- User-configurable Redundant IP address

- Time synchronization to SNTP time server on Ethernet network (when used with  Release 5.00 or later CPU module).
