DESCRIPTION
The MD00R-02 and MD00R-04 fulfill the need for a powerful yet cost effective operator interface system in areas where space and cost must be small. Displays are available with either two or four lines in a backlit LCD. Each line can contain up to 20 characters. Each page can contain up to 32 lines, which can be accessed by scrolling with the arrow keys. Brightness control is provided to adjust the display for easy viewing under nearly any condition.
Display Variables
PLC internal variables can be shown on any of the many display pages (limited only by memory size). The number of variables that can be viewed at one time is limited only by the display size. UniOP also provides scaling (linear conversion) of the displayed data. The final value can then be shown in several useful formats including decimal, bit, hexadecimal, floating point, and string. Data entry with valid range verification is also available for each data type.
Data Entry
The integral keypad on the MD00R-02 and the MD00R-04 offer 4 function keys and 4 user LEDs, as well as four arrow keys, a CLEAR key and an ENTER key. The arrow keys can be used to increment or decrement any data field. Slide-in legends make it easy to customize and document the operation of the function keys.
Adaptability
Custom display screens are developed using the UniOP Designer™ for Windows™ programming software. Your completed project file can be downloaded to the display through the serial port and permanently stored in Flash EPROM.
MD00R-02/04 Features
NEMA 4/12 compliant enclosure
CE approved
·Keyboard Macro Editor
·One RS-232 / RS-422 / RS-485 / 20mA current loop serial port, speeds up to 38,400 baud for direct PLC connection
·One auxiliary port for high speed bus network communications
·4 configurable function keys with LEDs and slide in legends
·128 KB internal memory standard Flash EPROM
·Unlimited number of variables per page
·256 prioritized alarms Eight-level password protection
·Cursor, Help, Clear, and Enter keys
·Displays ASCII standard character set
Cutout Depth:64mm (2.52")
Front Panel Thickness (max.):5 mm (0.20")
Face-plate Height:109 mm (4.29")
Face-plate Width:149 mm (5.87")
Weight:0.9kg (2.0 lb)
Environment
Operating Temperature:0 to 50o C (32 to 122o F)
Humidity:0 to 95% RH (non-condensing)
Power Requirements:250 mA maximum, 24 VDC
Type:Liquid Crystal
Size:2 or 4 lines x 20 characters/line
Character height:5.15 mm (13/64 inch)
APPLICATIONS
• Simulation
• Instrumentation
• Industrial control
• Process control and monitoring
• Factory automation
• Intelligent networked PLC controllers
• Automated test
• Data acquisition
