FOXBORO CPCI-680 Universal Mode’ Single Board Computer
FOXBORO CPCI-680 Universal Mode’ Single Board Computer
Highlights
The Force PowerCore™ CPCI-680 CompactPCI® (6U) single board computer brings new levels of flexibility and power to embedded telecommunications, data communications and industrial applications. The first product based on Force’s pioneering Sentinel™ “universal” PCI-toPCI bridge technology, the PowerCore CPCI-680 can function as a high-performance system controller or an intelligent peripheral card, without any need for hardware or software reconfiguration when switching between operating modes. This, combined with its advanced PowerPC™ 750 or PowerPC G4 7400 processor and broad array of interfaces, makes the PowerCore CPCI-680 an ideal choice for configuring fast-to-market, highly reliable multicomputing platforms.
Features
■ Force’s Sentinel “universal-mode” PCIto-PCI bridge—enables SBCs to switch between system- and peripheral-slot functionality
■ PowerPC 750 or PowerPC G4 7400 processor/up to 1GByte high-speed memory for “supercomputing” performance
■ Ideal for Linux™ or real-time operating systems (RTOSes)
■ Low-power consumption
■ Up to three independent Fast Ethernet interfaces
■ Fast Wide SCSI-2 interface
■ Full Hot Swap support for CompactPCI
■ Up to two PMC slots
■ Single-slot solution
‘Universal-mode’ CompactPCI single board computer solution
■ Dual functionality: system slot and/or peripheral slot capabilities
■ Based on Force Sentinel “universal-mode” PCI-to-PCI bridge technology
■ “Zero” hardware or software impact when switching operating modes
■ Ready-made building block for multiprocessor systems
■ Single-slot solution—even fully configured
Flexible configurations
■ Up to two PMC slots
■ Up to three onboard independent Fast Ethernet interfaces
■ Two onboard serial interfaces
■ Optional interfaces (occupies one PMC slot)
■ Fast Wide SCSI-2 interface for mass storage
■ Four additional serial interfaces
■ Onboard CompactFlash interface for Type II cards
High-performance embedded computing platform
■ Optimum computing performance in a single 6U CompactPCI slot
■ PowerPC 750 or PowerPC G4 7400 processor, at 450/500MHz or 400MHz
■ Up to 1GByte SDRAM via memory modules
■ Built-in buffers in Sentinel allow fast data transfers across the widely deployed 32-bit CompactPCI bus
■ Low-power consumption for embedded applications
■ OS flexibility—broad Linux and real-time operating system (RTOS) support
Enabling power of Force’s Sentinel ‘universal’ PPB
The Force PowerCore CPCI-680 is a powerful and versatile CompactPCI single board computer (SBC) based on Force’s revolutionary Sentinel “universal-mode” PCI-to-PCI bridge (PPB). Intelligent Sentinel technology enables the PowerCore CPCI-680 to function as either a system controller (in a CompactPCI system slot) or as an intelligent peripheral card (in a CompactPCI peripheral slot). The Sentinel PPB completely eliminates the need for either hardware or software reconfigurations when the PowerCore CPCI-680 switches operating modes. By using the Sentinel PPB technology, developers can simplify and accelerate the design of multi-processor systems based on cost-effective, industry-standard components.
Broad expansion and I/O flexibility in a single slot
In addition to its versatility and high performance, the PowerCore CPCI-680 provides developers with broad expansion capabilities and a wide range of interface options. Up to two PMC slots are available for expansion, and an optional Fast Wide SCSI-2 interface enables high-speed connection to mass storage. There are also up to three independent Fast Ethernet interfaces and two serial interfaces (expandable to a total of six serial interfaces) for maximum I/O flexibility.
The optional onboard socket for Type II CompactFlash cards allows easy and flexible expansion via removable cards that can be either solid-state flash memory cards or diskbased media. Yet even when fully configured with a complete set of interfaces and its maximum 1GByte memory, the PowerCore CPCI-680 remains a single-slot solution.
Processor/memory
■ PowerPC 750 or PowerPC G4 7400 processor, at 450/500MHz or 400MHz
■ Up to 256MBytes onboard ECC-protected SDRAM (option to 1GByte via memory module)
■ 1 or 2MBytes L2 Cache running at half processor speed
■ Up to 16MBytes onboard programmable User Flash
■ 1MByte Boot Flash
