bently 3500/05 System Rack
bently 3500/05 System Rack
Description
Use the 3500 System rack to mount all 3500 monitor modules and power supplies. The rack allows you to place 3500 modules near one another, enabling them to easily communicate, and to mount power supplies necessary to distribute power to each module
3500 racks are available in two sizes:
Full-size rack. 19-inch EIA rack with 14 available module slots.
Mini-rack. 12-inch rack with seven available module slots.
You can order 3500 racks in three formats:
Panel mount. This rack format mounts to rectangular cutouts in panels, and secures to the panel using clamps supplied with the rack. Wiring connections and I/O modules are accessible from the rear of the rack
Rack mount. This rack format mounts the 3500 Rack on 19- inch EIA rails. Wiring connections and I/O modules are accessible from the rear of the rack.
Bulkhead mount. This rack format mounts the rack against a wall or panel when it is not possible to access the rear of the rack. Wiring connections and I/O modules are accessible from the front of the rack. The 3500/05 Mini-Rack is not available in this format
Compliance and Certifications
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
· This device may not cause harmful interference.
· This device must accept any interference received, including interference that may cause undesired operation.
EMC
European Community Directive: EMC Directive 2014/30/EU
Standards: EN 61000-6-2 Immunity for Industrial Environments
Electrical Safety
European Community Directive: LV Directive 2014/35/EU
Standards: EN 61010-1
European Community Directive: RoHS Directive 2011/65/EU
Ordering Considerations
Racks with Internal Barriers installed require a 3500/04-01 Internal Barrier Earthing Module to provide the IS Earth connection to the 3500/05 rack. This earthing module requires a dedicated rack position.
The 3500/93 System Display A01 System Face Mount option is incompatible with the 3500/05 Mini-rack.
The 3500/05 mini-rack is not available in the Bulkhead Mount option.
The 3500/06 weatherproof housing is not compatible with the 3500/05 Bulkhead Mount option.
When using a 3500 mini-rack in an EIA rack, a 144863-01 19-inch EIA Adapter Panel is required.
The 3500 mini-rack requires Version 2.70 or later of the 3500/01 Software
