GE PACSystems RX7i, RX3i and RSTi-EP  TCP/IP Ethernet  Communications


GE PACSystems RX7i, RX3i and RSTi-EP  TCP/IP Ethernet  Communications

Ethernet Interfaces for PACSystems Controllers

A PACSystems Ethernet Interface enables a PACSystems controller to communicate with other PACSystems  equipment and with Series 90 and VersaMax controllers. The Ethernet Interface provides TCP/IP  communications with other PLCs, host computers running the Host Communications Toolkit or CIMPLICITY  software, and computers running the TCP/IP version of the programming software. These communications use  the proprietary SRTP and Ethernet Global Data (EGD)1 protocols over a four-layer TCP/IP (Internet) stack.  The Ethernet Interface has SRTP client/server capability. As a client, the Interface can initiate communications  with other PLCs that contain Ethernet Interfaces. This is done from the PLC ladder program using the  COMMREQ function. As a server, the Ethernet Interface responds to requests from devices such as PLC  programming software, a Host computer running an SRTP application, or another PLC acting as a client.

Rack-based and RX7i Embedded Interfaces - Features

▪ Full RX3i Controller programming and configuration services with inactivity timeout

▪ Periodic data exchange using Ethernet Global Data (EGD)

▪ EGD Commands to read and write PLC and EGD exchange memory over the network.

▪ TCP/IP communication services using SRTP

▪ SRTP Client (Channels)

▪ Modbus TCP Server, supporting Modbus Conformance classes 0, 1, and 2.

▪ Modbus TCP Client, supporting Modbus Conformance classes 0, 1, and Function Codes 15, 22, 23, and  24 for Conformance class 2.

▪ Redundant IP Addressing capability.

▪ Basic remote PLC monitoring from a web browser (RX7i CPU Ethernet interface only)

▪ Comprehensive station management and diagnostic tools

▪ Extended controller connectivity via IEEE 802.3 CSMA/CD 10Mbps and 100Mbps Ethernet LAN port  connectors.

▪ Network switch that has Auto negotiate, Sense, Speed, and crossover detection.

▪ Direct connection to BaseT (twisted pair) network switch, hub, or repeater without an external  transceiver.

▪ Protocol is stored in flash memory in the Ethernet interface and is easily upgraded through the CPU  serial port.

▪ Communications with remote PLCs and other nodes reachable through routers. The gateway IP  address must be configured.

▪ Internet access via web pages served up to standard web browsers, for the Ethernet interface  embedded in the PACSystems RX7i CPU.

RX3i & RSTi-EP Embedded Ethernet Interface - Features

▪ Full RX3i controller programming and configuration services with inactivity timeout

▪ TCP/IP communication services using SRTP.

▪ SRTP Client (Channels)

▪ Modbus TCP Server, supporting Modbus Conformance classes 0, 1, and 2.

▪ Modbus TCP Client, supporting Modbus Conformance classes 0, 1, and Function Codes 15, 22, 23, and  24 for Conformance class 2.

▪ Communications with remote PLCs and other nodes reachable through routers. The Gateway IP  address must be configured.

▪ Comprehensive station management and diagnostic tools. For supported commands, refer to the  PACSystems TCP/IP Ethernet Communications Station Manager User Manual, GFK-2225J or later.

CPE302/CPE305/CPE310

▪ Extended controller connectivity via IEEE 802.3 CSMA/CD 10Mbps and 100Mbps Ethernet LAN port  connectors.

▪ Network switch that has Auto negotiate, Sense, Speed, and crossover detection.

▪ Direct connection to BaseT (twisted pair) network switch, hub, or repeater without an external  transceiver.

CPE330/CPE400/CPL410

• Two independent 10/100/1000 Ethernet LANs under the control of the embedded RX3i PLC. Port 1  attaches to LAN1 through a dedicated RJ45 connector. Port 2 attaches to LAN2 through a pair of  internally-switched RJ45 connectors. Space is provided to mark in the two corresponding IP  addresses.

• The embedded Ethernet interface permits the CPU to support two LANs.

• CPE400 has a third Ethernet port (located on the underside) which is under the control of Field Agent.

• CPL410 also has a third Ethernet port (located on the underside) which is under the control of the  Linux OS.

RSTi-EP CPE100/CPE115

• Two independent 10/100 Ethernet LANs. Port 1 attaches to LAN1 through a dedicated RJ45  connector. Port 2 attaches to LAN2 through three internally-switched RJ45 connectors.

• The embedded Ethernet interface permits the CPU to support two LANs.

Ethernet Interface Specifications

Connectors

- Two 10BaseT / 100BaseTX Ports: 8-pin female shielded RJ-45, autosensing

- Station Manager (RS-232) Port: 9-pin female D-connector

Maximum number of  connections

48 SRTP Server connections. Includes:

▪ A maximum of 16 Modbus/TCP Server connections

▪ A maximum of 32 communication channels. (Each channel may be an  SRTP Client or a Modbus/TCP Client. Any given channel can be assigned to  only one protocol at a time.)

Embedded Ethernet Switch:Yes – Allows daisy chaining of Ethernet nodes.

Serial Port:Station Mgr Port: RS-232 DCE, 1200 - 115200 bps.
