ABB POT 06 Operator Keypad POT 06 H&B Contronic
❤ Add to collection

ABB POT 06 Operator Keypad POT 06 H&B Contronic

+86-15305925923
Mr.Wang
wang@kongjiangauto.com
POT 06 Operator Keypad POT 06 H&B Contronic
6571.00
¥1990.00
Weight:2.000KG
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description
POT 06 Operator Keypad POT 06 H&B Contronic

ABB POT 06 Operator Keypad POT 06 H&B Contronic

Basic introduction

ABB POT 06 Operator Keypad POT 06 H&B Contronic is an operator keypad designed by ABB for H&B Contronic systems. It is intended for use in industrial control environments to facilitate the operation of the system.

Functional features

Convenience of operation

Reasonable layout: The key layout has been carefully designed to take into account the operator's operating habits and efficiency. It usually contains numeric keys, function keys (e.g., confirm, cancel, page up/down, etc.), which are arranged in such a way that the operator can quickly locate and press the desired key. For example, the numeric keys are usually arranged in a regular calculator-style layout for easy data entry, while the function keys are distributed around the numeric keys for easy operation.

Good tactility: Keys have a good tactile feel and give the operator clear feedback when they are pressed, allowing the operator to confirm that the key press was successful. This feedback can be the physical touch of a mechanical key or the slight elastic feedback of a membrane key, which helps to improve the accuracy of the operation.

System Compatibility

Tight Integration: The keypad is tightly integrated with the H&B Contronic system and accurately transmits commands entered by the operator to the system. It understands and follows the system's communication protocols, ensuring that commands corresponding to keystroke operations are correctly recognized and executed by the system. For example, when the “Start” function key is pressed, it sends a start command in a way that the system understands, enabling the relevant equipment in the system to start running.

Wide range of adaptations: A wide range of devices and applications can be adapted to the H&B Contronic system. Whether controlling simple sensor devices or complex automated production line equipment, the keypad can be configured and programmed to support the operation.

Durability and Reliability

Rugged and durable: Manufactured from robust materials that can withstand the physical elements of an industrial environment. The enclosure can resist a certain degree of impact, vibration and intrusion of dust and liquids. For example, in the factory floor, where there may be mechanical vibration and dusty environment, it can maintain good performance and will not be easily damaged.

Stable operation: It is very stable in signal transmission and electrical performance. It can work normally within a certain voltage fluctuation range, and it adopts anti-interference technology to ensure that in industrial environments with strong electromagnetic interference (such as environments where there are a large number of motors, inverters and other equipment), the signals generated by key operation can be accurately transmitted to the system without any loss of signals or errors.

Technical Parameters

Key information

Number of keys: the number of keys is generally around 10 - 20, the specific number depends on its functional design. In addition to the basic numeric keys (0 - 9), there will be some function keys to meet the basic needs of system operation.

Key type: Mechanical keys or membrane keys. Mechanical keys have a long service life and good tactile sensation, while membrane keys are more compact and well sealed to prevent dust and liquids from entering.

Interface

Interface type: Usually adopts the standard industrial interface, such as RS-232 interface, USB interface or RS-485 interface. These interfaces are convenient to connect with the system host or other control devices, and have good versatility and compatibility.

Transmission rate: The data transmission rate of the interface can meet the real-time operation requirements of the system, generally between 9600bps - 115200bps, to ensure that the commands of key operation can be transmitted to the system in time.

Working environment parameters

Temperature range: It can work normally in a wide temperature range, such as - 10℃ - +50℃, adapting to different industrial temperature conditions, whether in the cold outdoor equipment control environment or in the warm indoor workshop environment.

Humidity range: the relative humidity range is generally between 10% - 90% (non-condensing), can work stably under a certain humidity conditions, to avoid damage to electronic components or performance degradation caused by humidity problems.
