ABB PFTL 101A/B Web tension measurement
❤ Add to collection

ABB PFTL 101A/B Web tension measurement

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

ABB PFTL 101A/B Web tension measurement

28756.00
¥28740.00
Weight:4.000KG
Quantity:
(Inventory: 31)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

ABB PFTL 101A/B Web tension measurement


ABB PFTL 101A/B Web tension measurement

DESCRIPTION

Sensitivity and accuracy  combined with ruggedness  make the PillowBlock ideal make the PillowBlock ideal for applications with low  tensions, heavy rolls and  high speed high speed

Seven capacity ranges from  0.5 to 20kN / 113 to 4500lbs.

Versions for acid resistant  design available

 Ideal for accurate and reliable Horizontal force measurement – PFTL 201C/D

 Ideal for accurate and reliable measurement of wire and  felt tension in paper machines.

 Available in five different sizes with  nominal loads from 10kN up to  100kN.

 Mill-duty version (PFTL201CE/DE)  has enhanced protection with fixed  connection cable and protection hose.

 Stainless steel, SIS 2387 Corrosion resistance similar to AISI 304 Corrosion resistance similar to AISI 304

 Extremely good repetability error,  <0,05%

FOR PFTL 101/201/PFCL 101 Web Tensiometer Products

Specification

 Temperature range -25° to +90° C p g

 Cable 4x AWG17

 Bending radius 10x cablediam

 Resistance 86 ohm/km at 20° C

 Testvoltage 1000 VAC

Main Features

 Interactive menu for fast set-up

 Multi-language display C iii ith ith t &

 Commissioning with or without rope & weights

 Continuous self-diagnostic function g

 Profibus communication

 Selectable filter function

 Max. load memory

 Short-circuit proof inputs and outputs

 Approved acc. to CE, UL and CSA  standards

Current or Voltage Configuration of analog outputs

 Current or Voltage

 Connect signals (A,B… A+B, AB…)

 Filter times

 High Tension (N, kN, lbs, kg)

 High Output (max 21 mA or 11 V)

 Low Tension (N, kN, lbs, kg)

 Low Output (min 0 mA or –5 V)

 High Limit [mA or V]

 Low Limit [mA or V]

The transducer senses the Load cell design - PFTL 101

 The transducer senses the resulting shear force produced  between top and bottom of the  load cell load cell.

 The high spring constant g g pg gives  a deflection of only 0.015 mm  (0.0006 inch) at nominal load.

 Stable and accurate output  even when subjected to  intense vibrations intense vibrations.
