ABB PDP800 SD Series PROFIBUS Interface
ABB PDP800 SD Series PROFIBUS Interface
DESCRIPTION
Symphony® Plus is the new generation of ABB’s widely acclaimed Symphony family of distributed control systems – the world’s most widely used DCS in the power generation and water industries. In all, there are more than 6,500 Symphony DCS installations in operation all over the world, more than 4,500 of which are in power and water applications.
Seamless intelligent fi eld device integration
Symphony Plus controllers seamlessly integrate field devices through its PDP800 PROFIBUS interface module. This allows access to a wide range of intelligent field devices including transmitters, actuators, motor control centers (MCC), flame scanners, intelligent electronic devices, etc, from ABB and other third-party vendors. PROFIBUS I/O and related control strategies are configured using ABB’s extensive set of field-proven standard function code algorithms and S+ Engineering’s graphical design tools. Furthermore, this data is provided to other S+ system nodes (ie, control, operation, engineering and information) over the redundant Plant Network (PN800).
PDP800 PROFIBUS interface features include:
− Supports PROFIBUS DP V0, V1, V2
− Supports PROFIBUS PA devices through DP/PA linking device
− Supports 1 msec time stamping of devices by PROFIBUS DP V2
− Supports electric and fi ber optic media for PROFIBUS DP link
− Up to 12 Mbps rate of PROFIBUS DP link
− Up to 15 km by fi ber optic PROFIBUS DP link
Comprehensive I/O support
The PDP800 module enables the connection of Symphony Plus controllers to S800 I/O via PROFIBUS DP V2. S800 I/O provides options for all signal types, ranging from basic analog and digital inputs and outputs to pulse counters and intrinsically safe applications. S800 I/O sequence of events functionality is supported by PROFIBUS DP V2 with 1 msec accuracy event time stamping occurring at the source.
Additionally, the PDP800 supports Symphony Plus controllers’ connectivity to S+ Turbine’s specialty modules. Specifi cally, via PROFIBUS DP V2, the HPC800 can support powerful turbine control solutions for turbine protection (TP800), valve positioning (VP800), generator auto synchronization (AS800) and condition monitoring (MCM800).
Using fi ber optic extensions, PROFIBUS I/O modules and devices can be placed up to 15 km from the PDP800. Additionally, PDP800 modules can be located up to 3 km from the controller via redundant HN800 fi ber optic communications.
High reliability and availability
The PDP800 supports full redundancy at all levels, including the PDP800 module, power supplies, PROFIBUS DP link, and controller communication bus (HN800). All redundancy options are independent from each other to ensure the highest level of availability and reliability
Data accessible by control application
PROFIBUS device cyclic data is accessed by function code control applications in Symphony Plus controllers. Data can be calculated, used as part of a control strategy, or for display and alarming at the S+ Operations console.
Manage intelligent field devices
PROFIBUS devices are fully integrated with the Symphony Plus system, yielding benefits far beyond reduced footprint and cable costs. Within the S+ Engineering workbench, the Field Engineering tool supports configuration, commissioning and maintenance of PROFIBUS devices using device type manager (DTM) technology. For field devices that have conventional device description files (GSD), a basic PROFIBUS DTM is available to allow standardized configuration. The individual device DTMs can be accessed from Composer’s multiple data views, such as the system or location overview, and others. It includes automatic net calculation and loading of process items by using the device-specific channel configuration generated from the DTM.
