ABB POT25 Operator Keypad POT 25 H&B Contronic

ABB POT25 Operator Keypad POT 25 H&B Contronic

Technical parameters

Luminous wavelength and intensity: the light emitted by the light pen has a specific wavelength range, generally in the visible or near-infrared range, for example, the wavelength of 650nm - 780nm between. The intensity of light emitted is moderate, which can ensure that it is effectively received by the light sensor of the system, but will not cause harm to human eyes or interfere with the surrounding environment.

Positioning accuracy: the positioning accuracy can reach a very high level, such as the positioning accuracy on the screen can reach ± 0.1mm or so, depending on the optical design of the light pen and the degree of coordination of the system.

Working distance range: a certain working distance range, generally between a few millimeters to tens of centimeters. Within this distance range, the light pen can effectively interact with the system, different operations may correspond to different optimal working distance, for example, clicking operations may require a closer distance, while the distance can be used for cursor movement and other operations.

Application Scenarios

Industrial automation control

Equipment monitoring and operation: In the monitoring room of an industrial automation system, the operator can use the light pen to view and operate the status of the equipment on the monitoring screen. For example, by clicking on the device icon on the screen with the light pen, the detailed operation parameters of the device can be viewed; by dragging the operation, the operation mode or setting value of the device can be adjusted, and this kind of intuitive operation improves the operation efficiency and accuracy.

Program editing and debugging: When writing and debugging automation control programs, the light pen can be used to quickly locate lines of code, select function modules or set variable values on the programming interface. Compared with traditional keyboard and mouse operations, the light pen can operate more precisely in complex code structures, facilitating programmers' program development and optimization.

Process control systems

Parameter Adjustment and Monitoring: In process control systems such as chemical, power, and water treatment systems, light pens can be used to quickly adjust a variety of process parameters, such as temperature, pressure, and flow rate, on the operator interface. Operators can click or drag the light pen directly in the parameter display area to change the parameter value, and at the same time, they can select specific data points on the monitoring chart to view and analyze, so as to find and deal with abnormal situations in the process in a timely manner.

Intelligent Building Management System

System control and equipment management: In the management system of intelligent building, it is used to control and manage all kinds of equipment in the building. For example, through the light pen on the control interface of the building automation system, you can turn on or off the lighting equipment, adjust the temperature of the air conditioner, and set the mode of operation of the elevator. This intuitive operation facilitates the daily maintenance and management of building equipment by property managers.

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
