Brand
ABB SPQRS22 Quick Response Module
❤ Add to collection

ABB SPQRS22 Quick Response Module

+86-15305925923
Mr.Wang
wang@kongjiangauto.com
SPQRS22 Quick Response Module
12693.00
¥3337.00
Weight:2.000KG
Quantity:
(Inventory: 2)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description
SPQRS22 Quick Response Module

ABB SPQRS22 Quick Response Module

ABB SPQRS22 Quick Response Module is an important module in the field of industrial control and automation from ABB.

Functional features

Quick response capability

As the name suggests, quick response is the core feature of this module. In industrial environments, it is able to react to input signals in a very short time. For example, in a power system, when there is a sudden short-circuit fault or voltage fluctuation and other abnormal conditions, the SPQRS22 module can quickly capture the relevant signals and respond in milliseconds or even shorter, triggering the corresponding protection mechanism or control action.

This fast response mechanism helps to reduce the damage caused by industrial accidents to the equipment and safeguard the continuity and safety of the production process.

Signal processing function

The module is equipped with powerful signal processing capabilities, capable of processing many types of input signals, including analogue signals (such as 4 - 20mA current signals, 0 - 10V voltage signals) and digital signals (such as switching signals, pulse signals, etc.).

It can filter, amplify and convert the input signals to ensure the accuracy and validity of the signals. For example, for weak analogue signals from on-site sensors, the module can amplify them to a suitable range and remove noise interference by filtering, and then pass the processed signals to the control system for further analysis and processing.

Integration with other systems

The SPQRS22 module has been designed with compatibility and integration with other ABB equipment and systems in mind. It can be easily integrated into ABB's Distributed Control Systems (DCS), Programmable Logic Controllers (PLCs) and other systems to work in conjunction with other control modules.

For example, in a large-scale industrial automation project, the module can communicate with the PLC module and pass the processed signals to the PLC, which will make control decisions according to the preset logic program, thus realising precise control of the whole industrial process.

Technical Parameters

Response time

Typical response times can be in the millisecond range, e.g. between 1 - 10 ms, depending on the type of input signal and processing requirements. This fast response time is critical in industrial applications where time sensitivity is critical.

Signal Input Types and Ranges

For analogue signal inputs, common industry standard signals such as 0 - 10V voltage signals and 4 - 20mA current signals are typically accepted. For digital signal inputs, a wide range of digital signal types can be handled including TTL (Transistor Transistor Logic) level signals, RS-485 communication signals, and more.

Signal Processing Accuracy

High accuracy is achieved in signal processing. For example, analogue signals can be converted and processed with an accuracy of ±0.1% - ±0.5%, ensuring accurate processing and output of input signals.

Communication interfaces

Equipped with a variety of communication interfaces, such as Ethernet interface, RS-485 interface, etc., to facilitate data communication and networking with other devices. Through the Ethernet interface, the module can be connected to industrial Ethernet to achieve high-speed data transmission and remote monitoring; RS-485 interface can be used for stable communication with other field devices within a short distance.

Application Areas

Power system

SPQRS22 modules are used in substations and power plants for relay protection and automation. When a fault occurs in the power system, such as line short circuit, transformer overload, etc., the module can quickly detect the fault signal and trigger the relay protection device to act in time, such as disconnecting the circuit breaker of the faulty line, preventing the fault from expanding, and guaranteeing the safe and stable operation of the power system.

Industrial automation production line

In automated production lines, the module can be used to monitor and control production equipment. For example, in automobile manufacturing production line, it can be used to monitor the current and voltage signals of the robot welding equipment, and when the signals are abnormal, it will make a quick response, such as suspending the operation of the robot to prevent welding quality problems, and at the same time, it will send an alarm signal to the control system, which is convenient for the maintenance personnel to deal with it in time.

Process control system

In the chemical, pharmaceutical and other process control industries, SPQRS22 modules can be used to quickly monitor and control key parameters in the production process. For example, in the chemical production of reactor temperature control, the module can quickly collect the temperature signal inside the reactor and transmit it to the temperature control system, when the temperature is out of the set range, it will quickly activate the control mechanism of the heating or cooling device to ensure that the reaction is carried out at the appropriate temperature conditions.
