ABB GJR5253000R0277 Advant Controller

ABB GJR5253000R0277 Advant Controller

Basic information

Series: Part of ABB's Advant OCS series, which is widely used in industrial automation and is known for its high performance and reliability.

Place of origin: Usually Switzerland.

Dimensions and weight: Compact dimensions of approx. 85mm x 125mm x 60mm and a weight of approx. 0.5kg make it easy to install and integrate into a wide range of industrial control systems.

Performance features

Processor and Memory: A high-performance 32-bit RISC processor, equipped with 256KB of data memory and 480KB of programme memory, is capable of handling complex control tasks and large amounts of data storage quickly and efficiently, ensuring stable system operation.

Input and output configuration:

Analogue inputs and outputs: 8 analogue input channels and 4 analogue output channels, with a wide range of input and output signals, including 0-10V, 4-20mA and other common signal types, to meet the needs of temperature, pressure, flow and other physical quantities of measurement and control.

Digital input and output: 24 digital input channels and 16 digital output channels, which can be conveniently connected to various types of digital sensors and actuators, such as limit switches, relays, etc., to achieve the switching control and status monitoring of equipment.

Communication interface: Support RS-232, RS-485 and Ethernet communication interfaces, high communication rate and high stability, it can conveniently realise fast data communication with the host computer, other controllers or intelligent devices, build distributed control system, and meet the communication requirements in different industrial scenarios.

Operating temperature range: the working temperature range is from 0°C to 55°C, and the storage temperature range is from -25°C to 75°C, which can adapt to the more severe industrial environment temperature conditions and ensure stable and reliable operation in different working environments.

Application Areas

Industrial automation control system: in the chemical, pharmaceutical, food and beverage and other types of industrial production processes, as the core control unit, to achieve accurate control and monitoring of production equipment, improve production efficiency, product quality and stability of the production process.

Process control field: Widely used in the process control system for precise control of temperature, pressure, flow and other physical quantities, such as petrochemical, metallurgy, electric power and other industries of the production process control, through its rich input and output interfaces and powerful computing capabilities, to achieve real-time monitoring of process parameters and automatic adjustment.

Intelligent building automation system: It is suitable for building automation system in intelligent buildings, centralised control and management of air-conditioning system, lighting system, ventilation system, etc. It automatically adjusts the operating status of the equipment according to the environmental parameters and users' demands, improves the energy efficiency and comfort of the building, and realises energy saving, emission reduction and intelligent management.

OTHER INFORMATION

• Read the safety precautions carefully.

• Check the delivery for transportation damage. If damage is found, notify the  supplier as soon as possible.

• Do not use the operator panel in an environment with high explosive hazards.

• The supplier is not responsible for modified, altered or reconstructed  equipment.

• Use only parts and accessories manufactured according to specifications of the  supplier.

• Read the installation and operating instructions carefully before installing,  using or repairing the operator panel.

• Never allow fluids, metal filings or wiring debris to enter any openings in the  operator panel. This may cause fire or electrical shock.

• Only qualified personnel may operate the operator panel.

• Storing the operator panel where the temperature is lower/higher than  recommended in this manual can cause the LCD display liquid to  congeal/become isotopic.

• The LCD display liquid contains a powerful irritant. In case of skin contact,  wash immediately with plenty of water. In case of eye contact, hold the eye  open, flush with plenty of water and get medical attention.
