GE IC693CMM321 Industrial Ethernet module
❤ Add to collection

GE IC693CMM321 Industrial Ethernet module

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

The rapid development and widespread popularity of Ethernet communication, coupled with its unparalleled advantages of high speed and interconnectivity, have enabled Ethernet networking

News has become the factual standard and future development trend of high-speed communication in the field of industrial control worldwide.

GE Fanuc automation products support industrial Ethernet communication well and can be used for communication between control layer devices, as well as between control layer and remote devices

Communication between process I/O, control layer and human-machine interface HMI/touch screen.

¥19000.00
¥19000.00
Weight:3.550KG
Quantity:
(Inventory: 19)
Consultation
Accessories
  • ABB-Binary I/O m
    Original :¥15774.00
    With a price :¥15774
    Quantity
  • ABB-Optical star
    Original :¥9993.00
    With a price :¥9993
    Quantity
  •
    Original :¥
    0.00

      With the total price :¥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

The rapid development and widespread popularity of Ethernet communication, coupled with its unparalleled advantages of high speed and interconnectivity, have enabled Ethernet networking

News has become the factual standard and future development trend of high-speed communication in the field of industrial control worldwide.

GE Fanuc automation products support industrial Ethernet communication well and can be used for communication between control layer devices, as well as between control layer and remote devices

Communication between process I/O, control layer and human-machine interface HMI/touch screen.




GE IC693CMM321 Industrial Ethernet module

The rapid development and widespread popularity of Ethernet communication, coupled with its unparalleled advantages of high speed and interconnectivity, have enabled Ethernet networking

News has become the factual standard and future development trend of high-speed communication in the field of industrial control worldwide.

GE Fanuc automation products support industrial Ethernet communication well and can be used for communication between control layer devices, as well as between control layer and remote devices

Communication between process I/O, control layer and human-machine interface HMI/touch screen.

GE Fanuc industrial Ethernet communication products support the following industrial Ethernet protocols

SRTP TCP/IP protocol

EGD protocol

Modbus TCP/IP protocol (90-30-IC693CMM321, VersaMax-IC200EBI001,

Versapoint-IC220EBI001,IC200SET001)

product

GE Fanuc's PLC, DCS, Critical Control and other controller series products all support industrial Ethernet communication.

GE Fanuc provides remote I/O products that support industrial Ethernet communication functionality.

GE Fanuc provides serial/Ethernet converters for devices that only have serial communication to connect to industrial Ethernet communication,

Its serial protocol supports protocols such as SNP and Modbus RTU.

Network devices/media/speed

GE Fanuc Industrial Ethernet supports universal products such as Hub, Switch, Router, etc.

GE Fanuc Industrial Ethernet supports the following transmission media

Coarse coaxial cable Ethernet

Shielded STP/unshielded UTP twisted pair Ethernet

Thin coaxial cable Ethernet

Fiber optic Ethernet

Broadband transmission

Wireless Ethernet

GE Fanuc Industrial Ethernet supports a transmission rate of 10M/100M.


GE Fanue Automation Network and Communication

GE Fanuc Industrial Ethernet

2、 Introduction to the Principle of GE Fanuc Industrial Ethernet Protocol

SRTP TCP/IP protocol

SRTP TCP/IP protocol, also known as Service Request Transport Protocol. The SRTP TCP/IP protocol is developed by GE Fanuc

The proprietary Ethernet communication protocol is based on TCP/IP protocol at the bottom layer.

The SRTP TCP/IP protocol is based on the Client/Server structure and the Request/Reply method for Ethernet communication. The client is responsible for

The server sends a read/write data request and returns a corresponding reply to the client. The SRTP TCP/IP protocol can be used

Data communication, programming configuration download, controller HMI/touch screen communication, etc. between controllers of GE Fanuc products.

The SRTP TCP/IP protocol supports universal Hub, Switch, and Router products.

EGD protocol

EGD protocol, also known as Ethernet Global Data. EGD protocol is an efficient and convenient way to achieve communication between devices

A high-speed data communication protocol. The EGD protocol is based on UDP/IP protocol. Using EGD communication, users do not need to

Programming only requires configuring the parameters that need to be broadcasted (Producer) and received (Consumer).

In EGD communication mode, communication nodes are divided into Producer and Consumer. In EGD communication, the Producer follows the

The time period set in the Producer broadcasts data to the designated individual or group of consumers,

Consumers read the received data according to the time period set in the Consumer.

EGD communication belongs to a non connection oriented data transmission protocol, and compared with communication methods based on TCP/IP protocol, its communication

High efficiency, low system overhead, suitable for high-speed periodic communication applications. In GE Fanuc products, its communication cycle

The adjustable range is 10ms-3600s.

The EGD protocol supports products such as Hub, Switch, and Router, but for Switch/Router, it is required to support multiple UDP protocols

Target broadcasting.

The Modbus TCP/IP protocol is based on the Client/Server approach. Can be used for data communication between GEFanuc products, GE Fanuc

Communication between products and HMI/touch screens, as well as communication between GE Fanuc products and third-party manufacturer devices via Modbus TCP/IP protocol

Discuss communication, etc.

The Modbus TCP/IP protocol supports universal Hub, Switch, and Router products.

3、 Introduction to GE Fanuc Industrial Ethernet Communication Product Selection

PLC/DCS/Critical Control

GE Fanuc PLC products include PAC70, 90-70, 90-30, Versamax series. Industrial Ethernet Communication Connection

Please refer to the table below for the available options.

GE Fanuc DCS products include several series such as PA70, PA70H, and PA30, among which PA70 and PA70H are connected via Ethernet

Same as 90-70 PLC, PA30 Ethernet connection is the same as 90-30 PLC.

GE Fanuc Critical Control products include GMR (Triple Voting Safety Control System), HSB (90-70 Dual Machine)

Hot standby system), Max ON (90-30 dual machine hot standby system) and several series, including GMR, HSB and Ethernet connection

Same as 90-70 PLC, Max ON Ethernet connection is the same as 90-30 PLC.

series

model

describe

Supports Ethernet protocol

Number of interfaces

Port speed

PAC70 CPU module,

PAC70 PLC

IC698CPE010

2 RJ45 ports, internal

300Mhz, built-in embedded system

SRTP,EGD

10/100Mbps

Ethernet card

Install a dual port switch

Half duplex/Full duplex

PAC70 CPU module,

PAC70 PLC

IC698CPE020

700MHz, built-in embedded system

SRTP,EGD

2 RJ45 ports, internal

10/100Mbps

Ethernet card

Install a dual port switch

Half duplex/Full duplex

PAC70 PLC

IC698ETM001

PAC70 Ethernet module

SRTP,EGD

2 RJ45 ports, internal

10/100Mbps

Install a dual port switch

Half duplex/Full duplex

90-70 PLC

IC697CMM74290-70 Ethernet module

SRTP,EGD

1 RJ45 port

10Mbps

Half duplex

90-30 PLC

IC693CPU364

90-30 CPU364 module, internal

Install an embedded Ethernet card

SRTP,EGD

1 RJ45 port

10Mbps

Half duplex

90-30 CPU374 module: 133

90-30 PLC

1C693CPU374

Mhz, built-in embedded Ethernet

SRTP,EGD

2 RJ45 ports, internal

10/100Mbps

|Network card

Install a dual port switch

Half duplex/Full duplex

90-30 PLC

1C693CMM321

90-30 Ethernet module

SRTP,Modbus

10Mbps

TCP/IP

An RJ45 port

Half duplex

Versamax CPUE05 module

Versamax PLC

IC200CPUE05

Block, built-in embedded Ethernet

SRTP,EGD

1 RJ45 port

10Mbps

card

Half duplex/full duplex
