GE IS200RAPAG1BBA-W01 High-Performance Rack Power Supply Board for Industrial Controls

GE IS200RAPAG1BBA-W01 High-Performance Rack Power Supply Board for Industrial Controls

Model:IS200RAPAG1BBA-W01 Category:Industrial Control Module Type:Rack Power Supply Board Dimensions:11 x 6 x 6.7 cm Weight:0.14 kg Memory Device:1024-bit Serial Memory Board ID and Revision Info:Accessible via BRDID Data Line on P1 Connector Integrated Circuits:Multiple for Enhanced Functionality The GE IS200RAPAG1BBA is a state-of-the-art rack power supply board, engineered to provide reliable and efficient power management in the complex industrial environments of gas and steam turbines.

 Equipped with a high-capacity 1024-bit serial memory device, it ensures secure and quick access to essential board identification and revision details, crucial for maintenance and upgrade processes. Designed with precision for seamless integration into the GE Mark VI Speedtronic system, this board offers unparalleled compatibility and functionality, ensuring optimal performance across various industrial applications.

 Weighing just 0.14 kg and measuring 11 x 6 x 6.7 cm, it is lightweight and compact, facilitating easy installation and maintenance without compromising on power delivery capabilities. Access to board ID and revision information via the BRDID data line on the P1 connector enables quick and accurate troubleshooting, reducing downtime and enhancing operational efficiency. The GE IS200RAPAG1BBA Rack Board is a core component of the Mark VI Speedtronic System, specifically designed for efficient control of industrial gas and steam turbines.

OTHER INFORMATION

• Celeron™ socket 370-based single-board computer (SBC) with operating  system support for Windows NT®/Windows® 2000, Linux, VxWorks, QNX,  and Solaris

• Special features for embedded applications

— Up to 512 Mbyte IDE CompactFlash (optional)

— Three programmable 16-bit timers

— 32 Kbyte of battery-backed SRAM

— Remote Ethernet booting supported

— Software-selectable watchdog timer with reset

— Supports VMEbus P2 connection to HD/floppy drive

— PMC expansion site with VMEbus P2 I/O

— PC•MIP expansion site supported

— VME64 modes supported: A32/A24/D32/D16/D08(EO)/MBLT64/BLT32

— VMEbus interrupt handler, interrupter, and system controller

— Includes byte-swapping hardware for little-endian and big-endian data  interfacing (patent no. 6,032,212)

— Enhanced bus error handling

— Passive heat sink design (no moving parts)

• Standard features include

— Celeron socket 370 processor

— Up to 256 Mbyte SDRAM using one 144-pin SODIMM

— 64-bit Intel® AGP SVGA controller with 2 Mbyte SGRAM

— On-board Fast Ethernet controller supporting 10BaseT and 100BaseTX  interfaces

— On-board Ultra DMA/33 hard drive and floppy drive controllers with  VMEbus P2 I/O

— Two high-performance 16550-compatible serial ports

— PS/2-style keyboard and mouse port on front panel

— Real-time clock and miniature speaker included
