DESCRIPTION

The Foxboro I/A Series transmitters are a complete family of differential pressure, gauge pressure, and absolute pressure transmitters. Remote seals and flanged versions are available. IDP10 series intelligent two-wire DP cell transmitters measure the difference between two pressures and transmit a proportional or square root (flow) electrical signal, in either analogue or digital mode.

FEATURES

Application Versatility

Rugged Dependability

 Superior Performance

 Choice of Electronics Modules

 LCD Indicator / Pushbutton Configurator

 NEMA 4X / IP66 Protection

 CENELEC, CSA, FM and SAA Approval

 Choice of Electronics Modules

Maximum Static and Overrange Ratings

25 MPa, 3625 psi, 250 bar or kg/cm . (Either side may be higher pressure during overrange). Note that this value may be reduced when IDP10 is ordered with certain options.

Suppressed and Elevated Zero

Suppressed or elevated zero ranges are acceptable as long as the span and range limits are not exceeded.

Electrical Classification

Various certifications are available, including EExia IIC Instrinsically Safe Zone 0, EExd IIC Flameproof Zone 1 and ExN Non Sparking Zone 2.

Supply Voltage - mA Output：11.5 to 42 V DC

Relative Humidity：0 to 100%

Sensor Body Temperature

Silicone Fill Fluid : -46 to +121ºC

Fluorinert Fill Fluid : -29 to +121ºC

LCD Indicator and Push Buttons

Standard for IDP10-A and IDP10-I, optional for IDP10-D and IDP10-T. The indicator provides two lines; 5 numeric characters on the top line and 7 alphanumeric characters on the bottom line. The pushbuttons allow for configuration of:

- linear or square root output

- adjustable damping

- forward or reverse output

- failsafe output (upscale or downscale)

- re-ranging without applying pressure (not -I)

Optional External Zero Adjustment

External zero adjustment makes it easier to zero the transmitter in the field, especially in hazardous locations.

Physical Specifications

Process Cover and Sensor Materials

A wide range of process cover/sensor material combinations is available. Process cover materials include Carbon Steel, 316 S/S, Monel and Hastelloy C. Sensor materials include Cobalt-NickelChromium, 316L S/S, Gold Plated 316L S/S, Monel , Hastelloy C and Tantalum.

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
