Product Overview.

Basic information: ABB GJR5253100R0160 07KT98 Basic Unit with Arcnet is a basic unit from ABB's Advant OCS series, originating from Sweden, with dimensions of approximately 6 inches × 4 inches × 10 inches (15.2cm × 10.2cm × 25.4cm) and a weight of approximately 3 pounds, 1 ounce (1.4kg). 1.4kg).

Features: The basic unit is equipped with Arcnet network interface, can achieve efficient data communication between devices, suitable for building distributed control systems, to meet the requirements of industrial automation in the field of data transmission and control.

Performance Parameters

Input and output configurations:

Analogue input: 8 channels, the input range includes 0...+5V, -5...+5V, 0...+10V, -10...+10V, 0...20mA, 4... 20mA, Pt100 (2 or 3-wire) and other signal types, with resolutions ranging from 10, 11 and 12 bits.

Analogue outputs: 4 channels with output ranges of -10...+10V, 0...20mA and resolutions of 11, 12 bits.

Digital inputs and outputs: 24 channels of 24V DC digital inputs and 16 channels of 24V DC digital outputs, each digital output channel has an output current of 0.5A.

Storage capacity: 1MB for both user data and user programme, storage type includes Flash EPROM, non-volatile RAM, SMC, etc.

Application Fields

Industrial automation control system: Widely used in the automation control of various industrial production processes, such as chemical, pharmaceutical, food and beverage industries on the production line, to achieve the monitoring of production equipment, data acquisition and control, to ensure the stable operation of the production process and product quality consistency.

Energy management system: in the power, energy and other fields of energy management system, can be used to monitor and control energy equipment, such as substations, power plants and other places of equipment operation status, to achieve optimal distribution of energy and energy saving and emission reduction.

Intelligent building automation: It is applicable to building automation system in intelligent buildings, which can centrally control and manage air-conditioning system, lighting system, ventilation system, etc., and improve the energy efficiency and comfort of buildings.

Main features

· 24 digital inputs with LED displays

· 16 digital transistor outputs with LED displays

· 8 digital inputs/outputs with LED displays

· 8 individually configurable analog inputs 0...10 V, 0...5 V, ±10 V, ±5 V, 0...20 mA, 4...20 mA, differential inputs, Pt100 (2-wire or 3-wire), the analog inputs are also individually configurable as digital inputs

· 4 individually configurable analog outputs ±10 V, 0...20 mA, 4...20 mA

· 2 counters for counting frequencies up to 50 kHz, configurable in 7 different operating modes · 1 CS31 system bus interface for system expansion

· 1 interface for connecting communication modules (e.g. 07 KP 90)

· 2 serial interfaces COM1, COM2

– as MODBUS interfaces and

– for programming and test functions

· Real-time clock

· LEDs for displaying operating conditions and error messages

· Detachable screw-type terminal blocks

· Fastening by screws or by snapping the device onto a DIN rail

· The lithium battery 07 LE 90 can be put into the battery compartment in order to

– store and backup the user program in the RAM

– store and backup data which is additionally contained in the RAM, e.g. the status of flags

– backup the time and date (real-time clock)

· RUN/STOP switch for starting and aborting the program execution

· Extensive diagnosis functions

– self-diagnosis of the basic unit

– diagnosis of the CS31 system bus and the connected modules
