ABB 1SBP230103R1001 XM06B5 Extension Unit
❤ Add to collection

ABB 1SBP230103R1001 XM06B5 Extension Unit

+86-15305925923
Mr.Wang
wang@kongjiangauto.com
XM06B5 Extension Unit
Manufacturers
ABB

Model(s)
ABB Advant Controller 31, ABB Advant OCS

Estimated Shipping Size
  Dimensions: 4.0" x 4.0" x 5.0"
  (10.2 cm x 10.2 cm x 12.7 cm)
  Weight: 0 lbs 12.9 oz (0.4kg )
66324.00
¥1547.00
Weight:3.000KG
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description
XM06B5 Extension Unit
Manufacturers
ABB

Model(s)
ABB Advant Controller 31, ABB Advant OCS

Estimated Shipping Size
  Dimensions: 4.0" x 4.0" x 5.0"
  (10.2 cm x 10.2 cm x 12.7 cm)
  Weight: 0 lbs 12.9 oz (0.4kg )

ABB 1SBP230103R1001 XM06B5 Extension Unit

Functional features

Strong expansion capability: Strong expandability, supporting up to 16 digital inputs and outputs, which can meet the needs of industrial automation control system for monitoring and controlling a large number of digital signals.

Flexible configuration: each channel can be independently configured as a digital input or output, users can flexibly set the function of each channel according to specific application scenarios and control requirements, to achieve the processing of different types of digital signals.

Easy to install and maintain: with modular design, compact size and light weight, it can be connected to ABB PLC system through bus, which is convenient and quick to install, and easy to overhaul and replace in case of failure.

High reliability: high reliability and stability, suitable for a variety of harsh industrial environments, stable operation for a long time, reducing production interruptions caused by equipment failure.

Technical Parameters

Power supply voltage: generally DC24V, with DC1500V voltage isolation and reverse connection protection.

Power consumption: Typical power consumption is less than 4W.

Input and output channels: Up to 16 digital input/output channels.

Communication interface: Support Profibus DP bus standard, etc. The communication rate includes 9.6kBit/s, 19.2kBit/s, 45.45kBit/s, 93.75kBit/s, 187.5kBit/s, 500kBit/s, 1.5MBit/s, 6MBit/s, and 12MBit/s.

Application Scenarios

Manufacturing industry: such as automotive manufacturing, machining, electronic equipment manufacturing and other industries, can be used to monitor the operating status of production equipment, control the start and stop of automated production lines, product quality testing, and so on.

Chemical industry: used to monitor the temperature, pressure, flow and other parameters in the chemical production process, control the opening and closing of valves, pump start and stop, etc., to ensure the safety and stability of chemical production.

Power industry: it can monitor and control the operation status of power equipment, such as switch control of substation, signal acquisition of protection device of power system, etc.

Oil and gas industry: In oil extraction, refining and natural gas transmission, it is used to monitor the wellhead equipment, pipeline flow, pressure, etc., to achieve automated control and safe production.

Wastewater treatment industry: monitoring and controlling the water level, water quality, flow rate and other parameters in the process of wastewater treatment to ensure the effect of wastewater treatment and normal operation of equipment.

FEATURES

• Process Station with integrated fieldbus  capability

• 4 high-speed fieldbus lines

• Supports different fieldbus types, even  simultaneously:  PROFIBUS-DP, up to 12 MBd  Modbus  CAN  Foundation Fieldbus H1 (with LD800  HSE)

• Easy engineering:  fully integrated in Control Builder F

• One unified database for field devices  shared by the control level and the Human  System Interface (HSI)

• Module recognition with factory and operational parameters

• Comprehensive diagnostics for proactive  maintenance

• Compact, rugged design

• Front panel connectors

• DIN Rail (C-rail) or wall mounting for easy  installation

• Ambient temperature 0-60 °C (32-140 °F)  with temperature monitoring

• EMC certification according to EN50082

• Certification:  CE, NAMUR, CSA, UL, EN61000-6-2.

The AC 800F is available in two versions:

• 4 MB static RAM, 4 MB EPROM

• 16 MB synchronous dynamic RAM,   8 MB EPROM

The AC 800F optionally provides several levels  of redundancy:

• device redundancy with 2 AC 800F

• power supply redundancy (24 V DC)

• Ethernet communication redundancy   (standard)

• Cable redundancy for Profibus DP,   requires external equipment (RLM01)

AC 800F Controller Redundancy

Controller redundancy can be achieved by installing two  AC 800F. To ensure quick and smooth takeover by the secondary AC 800F in case the primary AC 800F fails, a dedicated  redundancy communications link through the second Ethernet  module makes sure that both AC 800F are always synchronized. All inputs and outputs are designed to support redundant  operation.
