ABB H&B Contronic XU 03 Module XU 03 H&B Contronic
Basic Information
Dimensions: length 12.7cm, width 5.1cm, height 20.3cm.
Weight: about 0.4kg.
Place of origin: Sweden.
Performance features
Input/Output Function: As an I/O module, it can be connected to various types of input/output devices, such as sensors, actuators, etc., to achieve signal acquisition and transmission.
Signal processing capability: capable of processing the input analogue or digital signals, including amplification, filtering, conversion and other operations, in order to improve the quality and accuracy of the signals and ensure that the control system can acquire accurate field data.
Abundant communication interfaces: Supporting a variety of communication interfaces, such as Profibus, Modbus, HART and other common protocols, it is convenient to connect and exchange data with other devices, and can be easily accessed to PLCs, human-machine interfaces, and host computer monitoring systems.
High Reliability: Adopting high quality components and advanced manufacturing process, it has high reliability and stability, and can operate stably for a long time under the harsh industrial environment.
Operating Temperature Range: It can normally work under the ambient temperature from -25°C to +55°C, which can adapt to the temperature environment of different industrial sites.
Application Areas
Industrial automated production line: widely used in various industrial automated production lines, such as automotive manufacturing, machinery processing, food and beverage production, etc., used to monitor and control the temperature, pressure, flow, position and other parameters in the production process, to ensure the stable operation of the production line and the consistency of product quality.
Energy management system: in the power, petroleum, chemical and other energy industries, it can be used for monitoring and control of energy production, transmission and distribution process, such as monitoring of generator sets in power plants, equipment control in substations, energy metering in petrochemical enterprises, etc., to improve the efficiency of energy utilisation and management level.
Intelligent building field: In the automation system of buildings, such as air-conditioning system, lighting system, water supply and drainage system, etc., it can realise the monitoring and control of environmental parameters and equipment operation status, improve the comfort of the building and the efficiency of energy use, and reduce the operation cost.
FEATURES
• Process Station with integrated fieldbus capability
• 4 high-speed fieldbus lines
• Supports different fieldbus types, even simultaneously: PROFIBUS-DP, up to 12 MBd Modbus CAN Foundation Fieldbus H1 (with LD800 HSE)
• Easy engineering: fully integrated in Control Builder F
• One unified database for field devices shared by the control level and the Human System Interface (HSI)
• Module recognition with factory and operational parameters
• Comprehensive diagnostics for proactive maintenance
• Compact, rugged design
• Front panel connectors
• DIN Rail (C-rail) or wall mounting for easy installation
• Ambient temperature 0-60 °C (32-140 °F) with temperature monitoring
• EMC certification according to EN50082
• Certification: CE, NAMUR, CSA, UL, EN61000-6-2.
