GE Spectra RMS™ Circuit Breakers Electric machine
❤ Add to collection

GE Spectra RMS™ Circuit Breakers Electric machine

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

GE Spectra RMS™ Circuit Breakers Electric machine

28756.00
¥27740.00
Weight:4.000KG
Quantity:
(Inventory: 31)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

GE Spectra RMS™ Circuit Breakers Electric machine


GE Spectra RMS™ Circuit Breakers Electric machine

DESCRIPTION

These breakers are available only with interchangeable trip units. Two frame sizes are available, the 800 ampere frame (300 to 800 amperes) and the 1200 ampere frame (600 to 1200 amperes). Trip units are not interchangeable between frames. "Complete Circuit Breaker" price includes frame, trip, Cu/AI line, and load lugs. Units will be shipped unassembled unless specified "must be factory assembled." If line lugs are not required on the breaker, eliminate "WL" from catalog number and subtract price of line lugs.

R Frame—1000/1600/2000 Amp Molded-Case Circuit Breaker

• Solid-state MicroVersaTrip Plus™ or MicroVersaTrip PM™ Trip Unit

• Interchangeable trip unit via rating plugs

• 65 and 100 kA ratings available

• Standard and 100% rated versions

• Uses standard Power Break* accessories

• Stationary/manual only

Current Limiting Circuit Breakers

• 150, 225, 400 and 600 ampere frame sizes

• UL listed interrupting ratings are 200 kA at 240 and 480 volts ac maximum and 50 kA at 600 volts ac maximum

• Thermal magnetic construction

Circuit Breakers with MicroVersaTrip' Trip Units

• Solid-state construction with MicroVersaTrip RMS-9 digital rms sensing microprocessor trip units.

• Available in J and K frame construction with ampere ratings from 60-1200A.

How To Order:

• Determine the required breaker frame (i.e., 150, 400, 600, 800, or 1200 amperes), 1C rating, and load requirements (UL Standard or 100%). Determine overcurrent protective functions (LI, LSI, LIG, LSIG). Select frame catalog number and list price from table on page 4-27.

• Select and price the required rating plug from table below. The sensor rating of frame must match the sensor rating of the rating plug in table.

• Select and price lugs and lug covers as required from page 4-63.

• Select and price appropriate combination of Distribution Cable System accessories from pages 4-32 to 4-34.

• Select and price any other accessories from page 4-35 and 4-47 to 4-65.

• When ordering, specify separate catalog numbers as follows:

—Frame

—Rating Plug

—Lugs

—Distribution Cable Accessories

—Other Accessories

Standard Features

• Adjustable Long-Time (L) pickup, 0.5-1.OX, and delay (3-4 bands),

• Adjustable Instantaneous (I) pickup, 1.5-10X.

• Local Overload and Short-Circuit Trip Indicators (T) with overload pickup warning.

• Interchangeable trip rating plugs with test set jack for TVRMS test set.

• Digital LCD display with four-button keypad for function selection and set point adjustment and scalable, clear Lexan® cover for tamper-resistant settings.

• True rms sensing for accurate response to high harmonic content waveforms.

•EMI immunity per ANSI C37.90.

•POWER LEADER Communications System Link with user-selectable address assignment for COMNET communication.

•Metering

•3-Phase Ammeter with ±4% accuracy.

•3-Phase Voltmeter, ±2% @ 1X, configurable for Wye and Delta systems.

•Frequency Meter, ±1 Hz

•kW Meter, ±7% (real power) ;

•kVA Meter, ±6% (apparent power)

•kWh Meter, ±6% (energy)

•Control Power 24 Vdc provides connection capability for +24 Vdc control power into the breaker via the distribution cable system.

Optional Features

• Adjustable Short-Time (S) pickup, 1.0-9.0C, and delay (4 bands) with I2 t IN/OUT selection.

• Adjustable Ground fault (G) pickup, 0.2-1.OS, and delay (4 bands) with I2 t IN/OUT selection and trip indicator. The 4 short-time and ground fault delay bands provide broader system selectivity.
