HIMA X-DI6451 Digital Input Module

HIMA X-DI6451 Digital Input Module

This article is divided into the following main sections:

Introduction

Safety Precautions

Product Description

Start-up

Operation

Maintenance

Decommissioning

Transportation

Disposal

Additionally, the following documents must be taken into account:

Name Content Document no.

HIMax

System manual

Hardware description of the

HIMax system

HI 801 001 E

HIMax

Safety manual

Safety functions of the HIMax

system

HI 801 003 E

HIMax

Communication manual

Description of communication

and protocols

HI 801 101 E

SILworX Online Help

(OLH)

Instructions on how to use

SILworX

-

First Steps Introduction to SILworX HI 801 103 E

Table 1: Additional Relevant Manuals

The latest manuals can be downloaded from the HIMA website at www.hima.com. The

revision index on the footer can be used to compare the current version of existing manuals

with the Internet edition.

1.2 Target Audience

This document addresses system planners, configuration engineers, programmers of

automation devices and personnel authorized to implement, operate and maintain the

devices and systems. Specialized knowledge of safety-related automation systems is

required.

Formatting Conventions

To ensure improved readability and comprehensibility, the following fonts are used in this

document:

Bold: To highlight important parts

Names of buttons, menu functions and tabs that can be clicked and

used in SILworX.

Italics: System parameter and variables

Courier Literal user inputs

RUN Operating state are designated by capitals

Chapter 1.2.3 Cross references are hyperlinks even though they are not

particularly marked. When the cursor hovers over a hyperlink, it

changes its shape. Click the hyperlink to jump to the corresponding

position.

Safety notes and operating tips are particularly marked.

1.3.1 Safety Notes

The safety notes are represented as described below.

These notes must absolutely be observed to reduce the risk to a minimum. The content is

structured as follows:

ƒ Signal word: danger, warning, caution, notice

ƒ Type and source of danger

ƒ Consequences arising from the danger

ƒ Danger prevention

The signal words have the following meanings:

ƒ Danger indicates hazardous situation which, if not avoided, will result in death or serious

injury.

ƒ Warning indicates hazardous situation which, if not avoided, could result in death or

serious injury.

ƒ Warning indicates hazardous situation which, if not avoided, could result in minor or

modest injury.

ƒ Notice indicates a hazardous situation which, if not avoided, could result in property

damage.

NOTICE

Type and source of damage!

Damage prevention

SIGNAL WORD

Type and source of danger!

Consequences arising from the danger

Danger prevention

Safety

All safety information, notes and instructions specified in this manual must be strictly

observed. The product may only be used if all guidelines and safety instructions are

adhered to.

This product is operated in accordance with SELV or PELV. No imminent danger results

from the module itself. The use in Ex-Zone is permitted if additional measures are taken.

2.1 Intended Use

HIMax components are designed for assembling safety-related controller systems.

When using the components in the HIMax system, comply with the following general

requirements

2.1.1 Environmental Requirements

Requirement type Range of values

Protection class Protection class III in accordance with IEC/EN 61131-2

Ambient temperature 0...+60 °C

Storage temperature -40...+85 °C

Pollution Pollution degree II in accordance with IEC/EN 61131-2

Altitude < 2000 m

Housing Standard: IP20

Supply voltage 24 VDC

Table 2: Environmental Requirements

Exposing the HIMax system to environmental conditions other than those specified in this

manual can cause the HIMax system to malfunction.

2.1.2 ESD Protective Measures

Only personnel with knowledge of ESD protective measures may modify or extend the

system or replace modules.

NOTE

Device damage due to electrostatic discharge!

ƒ When performing the work, make sure that the working area is free of static and

wear an ESD wrist strap.

ƒ If not used, ensure that the device is protected from electrostatic discharge, e.g.,

by storing it in its packaging.
