ABB-266DSH-Differential pressure transmitters

ABB-266DSH-Differential pressure transmitters
Base accuracy

from 0.06 % of calibrated span (optional 0.04%)

Reliable sensing system coupled with very latest digital technologies

provides large turn down ratio up to 100:1

Comprehensive sensor choice

optimize in-use total performance and stability

10-year stability

0.15 % of URL

Flexible configuration facilities

.provided locally via local LCD keypad

TTG(Through-The-Glass) keypad technology

allows quick and easy local configuration without opening the cover,

even in explosion proof environments

IEC 61508 certification

version for SIL2(1oo1) and SIL3 (1002) applications

PED compliance

Category Ill for PS> 20 MPa,200 bar

.Sound Engineering Practice(SEP) for PS≤ 20 MPa,200 bar

WirelessHART version

.the battery powered solution compliant to IEC 62591

Best-in-class battery life

up to 10 years @ 32 s update time

in-field replaceable

Product in compliance with Directive 2011/65/UE (RoHS I)

In-built advanced diagnostics

Specification – electrical characteristics and options IEC 62591 WirelessHART® output Device type: 1a06hex (listed with HCF) Network ID: ABBhex (2747 decimal) Join keys: 57495245hex (1464422981) 4c455353hex (1279611731) 4649454chex (1179206988) 444b4559hex (1145783641). Power Supply 1x D-cell size lithium-thionyl chloride battery. Battery life: 10 years at 32 sec. update time, 8 years at 16  sec. update time or 5 years at 8 sec. update time. (at reference conditions of 25 ± 2 °C ambient temperature,  data routed from 3 additional devices, LCD off).  THE BATTERY CAN BE REPLACED IN FIELD, ALSO IN  HAZARDOUS CLASSIFIED AREA. Output signal IEC 62591 WirelessHART Version 7.5 (IEEE 802.15.4-2006);  Frequency band: 2.4 GHz DSSS Update rate: user selectable from 1 sec. to 60 min.  Integrated adjustable omnidirectional antenna  – Output radio frequency: maximum 10 mW (10 dBm) EIRP – Range: up to 300 m. (328 yds.) Minimum distance between antenna and person is 0.2 m.  (8 in.) Telecommunications directive Every wireless measuring device must be certified in accordance with the telecommunications directive, in this  case the frequency range. This certification is countryspecific. European directives Radio Equipment & Telecommunications Terminal  Equipment Directive 2014/53/UE to standards EN 60950- 1:2013. EN 62311:2008. EN 301 489-1 V1.9.2. EN 301 489-17 V2.2.1.  EN 300 328 v1.8.1. In Europe, use of the 2400 - 2483.5 MHz frequency band is  not harmonized. Country-specific regulations must be  observed. Restrictions for Norway Operation not permitted within a radius of 20 km around Ny-Alesund in Svalbard. For more information, see www.npt.no Norway Posts and Telecommunications site Extra-european radio frequency licences USA to FCC Part 15.247:2009;  Canada to IC RSS-210 and ICES-003;  Argentina; United Arab Emirates (UAE); India; Mexico. PROFIBUS® PA output Device type Pressure transmitter compliant to Profiles 3.0.1 Identification number: 3450 (hex) Power supply The transmitter operates from 9 to 32 V DC , polarity  independent, with or without surge protector. For Ex ia approval power supply must not exceed 17.5 V DC. Intrinsic safety installation according to FISCO model.  Current consumption operating (quiescent): 15 mA fault current limiting: 20 mA max. Output signal Physical layer in compliance to IEC 1158–2/EN 61158–2  with transmission to Manchester II modulation, at 31.25  kbit/s. Output interface PROFIBUS PA communication according to Profibus  DP50170 Part 2/DIN 19245 part 1–3.  Output update time  25 ms Data blocks 3 analog input, 1 physical. Additional blocks 1 Pressure with calibration transducer block 1 Advanced Diagnostics transducer block including  Plugged Input Line Detection 1 Local Display transducer block Transmitter failure mode On gross transmitter failure condition, detected by selfdiagnostics, the output signal can be driven to defined  conditions, selectable by the user as safe, last valid or  calculated value.  If electronic failure or short circuit occur the transmitter  consumption is electronically limited at a defined value  (20 mA approx), for safety of the network.
