ABB PGC5000A Generation 2 master controller

ABB PGC5000A Generation 2 master controller

Overview

The PGC5000A Generation 2 master controller  provides all analyzer system control functions and  coordinates internal and external data activities for all of the PGC5000 Series ovens. The new controller  also supports multiple smart oven configurations to  maximize application flexibility while minimizing  space and utility requirements. The Generation 2  controller is designed with a Real Time (embedded)  Operating System (RTOS) to guarantee critical system uptime, security and deterministic transfer  of data. The Human Machine Interface (HMI)  includes a 10.4 inch true color touchscreen SVGA  display, universal keypad and touch-pad mouse.

Features

Ease of use

• Graphics based touch screen HMI

• Supports multiple Smart OvenTM configurations,

• Up to 4 PGC5000B ovens

• Up to 2 PGC5000C ovens

• One PGC5000C with up to 2 PGC5000B ovens

Communication interfaces

• Ethernet, OPC, MODBUS, 4 to 20mA analog outputs, VistaNET 2.0 compatible

Enhanced Data Storage

• Up to 7 days of chromatograms and reports via removable SSD card

Standard inputs / outputs

• Eight isolated 4 to 20mA outputs

- Four digital outputs

- Dedicated purge alarm

- Dedicated common malfunction alarm

• Two additional configurable outputs

Application flexibility

• PGC5000B Smart Ovens target basic applications with a fixed set of features

• PGC5000C Smart Ovens target complex applications requiring multiple detectors for high application density

• PGC5007 oven targets flare gas monitoring and total sulfur process applications

• PGC5009 oven designed for fast temperature programmed simulated distillation analysis

Specification

Ambient temperature range：0 to 50° C (32 to 122° F)

Humidity：95% relative humidity, non-condensing

Dimensions (W x D x H)：596.9 mm x 419.1 mm x 256.5 mm  (23.5 in. x 16.5 in. x 10.1 in.)

Weight：20 kg (44 lbs) (minimum, configuration dependent)
