ABB SPA Bus Connection Modules fieldbus

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

ABB SPA Bus Connection Modules fieldbus

28756.00
¥27740.00
Weight:4.000KG
Quantity:
(Inventory: 31)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

ABB SPA Bus Connection Modules fieldbus


ABB SPA Bus Connection Modules fieldbus

DESCRIPTION

The SPA bus interconnects the substation  protection relays, annunciator systems and  other devices by means of a fibre-optic loop  based on a glass or plastic fibre cable. The  devices are connected to the bus over bus  connection modules type SPA-ZC_ which  convert the electrical signals of the devices to  optical signals for the bus and, vice versa, the  optical signals of the bus to electrical signals.

Features

• Electrical-to-optical converter for the SPA  bus

• Connects the substation secondary  devices to the fibre-optic SPA bus

• High immunity to electrical and electromagnetic interference

• Easy mounting and installation

• Complete range of bus connection modules for different applications

• Products of the SPACOM product family  and ABB’s Substation Automation system

Design

The SPA bus connection modules are used in  both ends of the SPA bus, i.e. on the substation level for connection of the bus to the  communication units and on the feeder level  for connection of the bus to the substation  secondary devices.

Bus connection module SPA-ZC 17

The bus connection module SPA-ZC 17 is  used for connecting substation secondary  devices to the SPA bus. It converts the TTL or  RS 485 level signals of the host device to fibre optic signals for the bus and vice versa.  The unit comprises one 9-pin D type connector for the host device and one pair of optical  transceivers for the SPA bus. The module can  be powered from the host device or from a  separate power source. In the latter case the  bus connection module and the fibre-optic  bus remain operative, should the power supply from the host device be interrupted.

Bus connection module SPA-ZC 20

The bus connection module SPA-ZC 20 is  used for multiplying the number of available  fibre-optic loops in a substation. The module  is provided with 15 transceiver pairs, that is it  can form 15 fibre-optic loops. All of the loops  formed by the module carry the same information. In certain applications, where operational reliability is of primary concern it can be recommended to limit the number of substation secondary devices connected to one  single loop. In these applications the bus connection module SPA-ZC 20 is applied. The SPA-ZC 20 is only used in master mode  and it is powered from the device to which it  is connected. The input interface of the  device is of the RS 485 type.

Bus connection module SPA-ZC 21

The bus connection module SPA-ZC 21 is  used for connecting substation secondary  devices to the SPA bus. It converts the TTL or  RS 485 level signals of the host device to  fibre optic signals for the bus and vice versa.  The unit comprises one 9-pin D type connector for the host device and one pair of optical  transceivers for the SPA bus. The module is  powered from the host device.

Bus connection module SPA-ZC 22

The bus connection module SPA-ZC 22 is  used for dividing the system into several  fibre-optic loops. The SPA-ZC 22 module is  available in two versions, one with five fibreoptic transceiver pairs and one with two pairs.  The SPA-ZC 22 module is connected to the  communicator units of the SPA loop. The bus  connection module features a built in  RS 232 C interface for direct connection to a  PC, a modem, etc. and one RS 485 interface  for connection to e.g. a SRIO unit. The bus  connection module can also be used in slave mode if a double connection to one substation  secondary device is needed. The third mode  of operation for the SPA-ZC 22 module is the  optical repeater mode. In the optical repeater  mode a fibre pair from the communicator  unit's optical module is connected to the first  transceiver pair of the SPA-ZC 22 module.  The data is then retransmitted over the other  transceiver pair(s) in the module.

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
