GE DS4820R20 Relay Module, 194B5704G1, Industrial Automation
Model Number:194B5704G1 Module Type:Relay Voltage Rating:120V AC/DC Current Rating:5A @ 24V DC Contact Rating:10A @ 250V AC, 16A @ 110V AC Operating Temperature Range:-40"C to +70"C Environmental Compliance:UL, CE, CSA Certified Dimensions:80mm x 80mm x 20mm Weight:0.15kg Introducing the GE DS4820R20 Relay Module (194B5704G1), an essential component for achieving optimal control and reliability in industrial automation systems.
This high-performance relay module boasts solid state technology for unparalleled precision and efficiency, making it the go-to choice for demanding applications. With a robust design capable of handling up to 5 amperes at 24 volts DC under load, this module ensures reliable operation even under heavy-duty conditions. Its contact rating of 100 watts guarantees long-lasting durability and minimal maintenance requirements. Operating within the temperature range of -40"C to +70"C, the DS4820R20 Relay Module is engineered to withstand extreme environmental challenges. Ideal for applications requiring high reliability and extended operational lifespan, it is a testament to GE commitment to quality and performance.
Designed with ease of integration in mind, this relay module features a versatile panel mount style, facilitating quick installation and compatibility with various control systems. Its 20 relays provide ample switching capacity for complex control scenarios, enhancing system flexibility and adaptability. Equipped with a voltage level input type and RS-485 communication interface, the DS4820R20 Relay Module seamlessly integrates into modern industrial networks, enabling seamless data exchange and enhanced system monitoring capabilities. This module is not just a component; it a key enabler of efficient and intelligent industrial operations. The GE DS4820R20 Relay Module offers industrial-grade reliability and precision for critical applications, ensuring seamless integration and optimal performance in harsh environments.
Features
Single slot CPU
Provides 1 Mbyte of battery-backed memory in the same slot (up to 512 Kbytes available for use by ladder diagram application program) Supports floating point calculations
Up to 12K discrete inputs and outputs (any mix - simplex mode only); 2048 voted discrete inputs, 2048 voted discrete outputs Up to 8K analog inputs (simplex mode only) and 8K analog outputs (simplex mode only); 1024 voted analog inputs
0.4 microseconds per boolean function
64 MHz, 80486DX2 microprocessor
Supports IC660/IC661 I/O (and IC697 I/O in simplex mode only)
Programmed by MS-DOS, or Windows
software products running on Windows
95 or Windows NT
over Ethernet TCP/IP or through the SNP port.
Configurable data and program memory
Battery-backed calendar clock
Three position operation mode switch
Password controlled access
Remote programmer keyswitch memory protection
Four status LEDs
Software configuration (No DIP switches or jumpers)
Reference information inside front door
In-system upgradable firmware
