GE VMIVME-2540 24-Channel Intelligent Counter/Controller

GE VMIVME-2540 24-Channel Intelligent Counter/Controller

PRODUCT OVERVIEW

The VMIVME-2540 Intelligent Counter/Controller (ICC) is a VMEbus slave I/O module designed to provide high-precision digital measurement and function generation capability for VMEbus systems with a simple, consistent memory-mapped user interface. The following functions are supported by the VMIVME-2540:

·Measurement Functions

Event counting

Frequency measurement

Period/pulse-width measurement

Quadrature position measurement

·Generation Functions

Pulse train/square wave generation

Timer/periodic interrupt generation

Frequency division

Quadrature position control

APPLICATIONS

• Rotational shaft instrumentation: angular position, velocity, acceleration

• Automotive industry testing: brakes, transmissions, tachometer

• Robotics

• Telescope/observatory

• Medical/laboratory instruments

• Linear position measurement: distance, velocity, acceleration

• Elevators

• Overhead cranes

SPECIFICATION

• Event counting - up to 4 giga events

• Frequency measurement —1.16 x 10-3 Hz to 2.5 MHz

• Period/pulse-width measurement—400 ns to 8.5899 x 106 s (32-bit floating point), 400 ns to 858 s (32-bit unsigned integer)

• Square wave/pulse train generation - 0.0076 Hz to 2.5 MHz

• Timer/periodic VMEbus interrupter - 0.0076 to 1,000 Hz

• Quadrature position measurement - sin/cos up to 1 MHz, 32-bit counters, limit/modulo checking

• Integer period/pulse-width measurement 16- and 32-bit, discrete or continuous; low data transport lags

• Programmed output - up to 24 discrete outputs

• Pulse sequence mode - train of N pulses with programmable duty cycle

• Quadrature position control outputs - ±1/4 wave control resolution; up to 1.25 MHz step rate and ±32767 steps per command

• Integer QPM group acquisition - captures two integer QPM measurements simultaneously

• Event-triggered timer delay - generates VMEbus interrupt up to 131.1 seconds after event edge input; retriggerable

• 24 control/measurement interfaces: 24 clocks, 24 gates, 24 outputs

• RS-422 differential interface with support for single-ended TTL inputs

• Options allow configurations of 4, 8, 16, and 24 interfaces

• On-board 15 MHz 68HC000 CPU

• A32/A24/D32/D16/D8 (EO) VME slave interface, 64 Kbyte VMEbus memory window

• Data exchange interface: ANSI/IEEE standard 754-1985 for 32-bit floating-point arithmetic

• Continuous measurement modes • VMEbus compatible ANSI/IEEE 1014-1987 IEC 821 and 297

• X-Y tables

• Machine tools

• Automatic storage retrieval

Input Frequency Range/Accuracy

16-bit Counter: 0.0076 Hz to 2.5 MHz

0.007 to 76 Hz Accuracy: 0.015 percent maximum

76 Hz to 2.5 MHz Accuracy: Percent Error = 100* (Frequency/5 MHz)

16-bit Enhanced-Resolution Counter: 0.001 Hz to 1.25 MHz Requires two 16-bit counters

16-bit Prescaler Range: ÷2-65536 with 2.5 MHz maximum clock rate
