GE HE693RTM705 Advanced RTU Master Communication Module
Module Type:Master Communication Module Brand:General Electric (GE) Model:HE693RTM705 Series:RTU Communication Protocol:RS-485/RS-232 Operating Temperature Range:-40"C to +70"C Power Consumption:Less than 1W Dimensions (mm):86 x 140 x 76 Weight:Approximately 150g Number of I/O Ports:8 Protocol Compatibility:Modbus RTU, ASCII, Binary Reliability Rating:IP67 (front panel) / IP20 (enclosure) The GE HE693RTM705 is designed for high reliability and robust performance in challenging industrial conditions. This communication module is a critical component for integrating diverse control systems, ensuring efficient data exchange and precise control over machinery and processes.
Featuring advanced compatibility with Modbus RTU, CANopen, and DeviceNet protocols, the HE693RTM705 offers unparalleled flexibility in connecting with various industrial devices. Its wide operating frequency range supports a broad spectrum of automation applications. With its compact yet rugged design, the module can withstand extreme environmental conditions, from freezing temperatures to high heat, making it ideal for deployment in factories, plants, and outdoor industrial settings.
Equipped with an energy-efficient power consumption profile, the GE HE693RTM705 minimizes operational costs while delivering high-speed data transmission rates. This ensures smooth operation and quick response times, crucial for maintaining productivity and efficiency in modern industrial operations. For ease of integration and maintenance, the module is equipped with intuitive diagnostics and configuration tools, enabling users to monitor system health and troubleshoot issues swiftly.
It also supports a wide voltage range, ensuring stable operation across different power sources. Backed by GE commitment to quality and customer support, the HE693RTM705 is supported by comprehensive documentation, technical assistance, and a warranty, providing peace of mind for long-term reliability and performance. The GE HE693RTM705 RTU Master Communication Module is designed for seamless integration in industrial control systems, offering high-speed data transmission capabilities for efficient monitoring and control across various industrial applications.
Compatibility
ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.
ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.
ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).
ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.
ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.
Module features include:
ƒ Support for all standard data rates (125K, 250K, 500K)
ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave
ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master
ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS
ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging
ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device
ƒ Support for configuration of the global scan rate
ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis
ƒ Support for PLC-application initiated explicit messaging via a COMMREQ
ƒ Master can be configured to operate as a slave simultaneously with master operation
ƒ Configurable fault behavior on loss of communication
ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)
ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)
ƒ Firmware update via service port on module
