GE IC695CPE305-AFAT PACSystems RX3i CPU Advanced Control for Industrial Automation
Processor Speed:200 MHz Memory:64 KB RAM, 32 KB EEPROM Operating System:GE Intelligent Platform Operating System Input/Output Channels:8 DI, 8 DO, 2 AI, 2 AO Power Supply:12-24V DC Communication Ports:1 x Ethernet, 1 x RS-485 Dimensions:96mm x 94mm x 35.5mm Weight:120g The GE IC695CPE305-AFAT PACSystems RX3i CPU is engineered for seamless integration into modern industrial control systems. Its advanced architecture supports real-time data processing and efficient communication protocols, ensuring optimal performance even in the most demanding conditions.
Equipped with a robust processor and ample memory, this CPU can handle complex algorithms and large datasets with ease, enhancing operational efficiency and productivity. With its versatile I/O capabilities, the IC695CPE305-AFAT offers precise control over actuators, sensors, and other devices, making it suitable for applications requiring high accuracy and reliability. Featuring an intuitive interface and comprehensive diagnostics, the CPU simplifies system monitoring and troubleshooting, reducing downtime and maintenance costs. Designed with durability in mind, this CPU operates within a wide temperature range (-40"C to +70"C), ensuring reliable operation in various industrial environments. The GE IC695CPE305-AFAT is a compact yet powerful micro modular controller designed for flexible and scalable automation solutions, ideal for various industrial applications requiring precise control and connectivity.
Compatibility
ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.
ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.
ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).
ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.
ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.
Module features include:
ƒ Support for all standard data rates (125K, 250K, 500K)
ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave
ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master
ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS
ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging
ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device
ƒ Support for configuration of the global scan rate
ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis
ƒ Support for PLC-application initiated explicit messaging via a COMMREQ
ƒ Master can be configured to operate as a slave simultaneously with master operation
ƒ Configurable fault behavior on loss of communication
ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)
ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)
ƒ Firmware update via service port on module
