GE IS230STAIH2A PLC MODULE High-Performance Control for Industrial Automation
Model:IS230STAIH2A Brand:GE Series:VIe Type:Control Circuit Board Weight:0.64 kg Material:Industrial-grade materials for durability Dimensions:Compact design for efficient use in space-constrained areas Operating Voltage:12 to 48 VDC Input/Output Channels:Flexible I/O configurations for versatile applications Communication Interface:RS-485 serial communication Reliability Rating:UL/CSA/CENELEC certified for safety and quality Warranty:1-year manufacturer warranty for peace of mind Integrating cutting-edge technology, the GE IS230STAIH2A PLC Module boasts a robust design that withstands harsh industrial environments. Its aluminum alloy construction ensures durability and lightweight portability.
This PLC module is equipped with an advanced VIe series, providing unparalleled performance in control circuit boards. It supports a wide range of applications, from simple automation tasks to complex industrial processes. With its ability to operate within a temperature range of -20"C to +60"C, this module is suitable for use in a variety of environments, from cold storage facilities to hot manufacturing plants. Featuring an RS-485 Modbus RTU communication interface, the GE IS230STAIH2A allows for efficient data exchange between devices, enhancing system connectivity and ease of integration. Engineered with high-quality components, this PLC module ensures reliable operation and long lifespan. Its 24V DC power supply provides stable energy to the system, guaranteeing consistent performance in industrial automation. The GE IS230STAIH2A PLC Module is a high-performance control solution designed for industrial automation, offering robust functionality and reliability in demanding environments.
Features
Complete Analog subsystem includes Base Converter and Expander modules
Base Converter module has eight differential inputs individually configurable for voltage or current
Accepts unipolar or bipolar Analog Inputs up to " 10 volts full scale
Accepts 4 to 20 milliamp current loop signals
Individual user scaling on each input channel on Base Converter module; scaling on a per module basis for Expander modules
Fast update rate for Base Converter module
Voltage and current Expander modules, each with 16 inputs, provides for additional inputs at a lower cost per point
Complete subsystem can accept up to 120 inputs
No jumpers or DIP switches to configure
Easy configuration with MS-DOS
or Windows
programming software configuration function.
Features
Single-Slot Module
SNP/SNP-X Protocol (master, slave)
CCM Protocol (master, slave, peer)
RTU Modbus Protocol (slave only)
Supports connection to MS-DOS or Windows
programming and configuration software package (monitor only)
12 Mhz, 80C186 Microprocessor
Two RS-422/RS-485 or RS-232 Serial Ports
CCM, RTU and SNP/SNP-X Available on Either or Both Ports
Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)
High Performance Access to PLC Memory
Three Status LEDs
Reset pushbutton
Soft Switch Configuration (no switches or jumpers)
No Battery Required
