GE IS239TRLYH1B Industrial Control System Circuit Board
Board Type:Industrial Control PCB Model Number:IS239TRLYH1B Dimension (LxWxH):33 cm x 17.8 cm x 5.5 cm Weight:1.42 kg Operating Temperature Range:-40"C to +85"C Power Supply Voltage:12V DC Communication Interfaces:RS-485, Modbus Reliability Rating:MTBF > 100,000 hours The GE IS239TRLYH1B printed circuit board is designed with cutting-edge technology to offer unparalleled performance in industrial environments. Its advanced design ensures seamless integration with existing systems, facilitating quick setup and operation. Crafted from high-quality, durable materials, this PCB is built to withstand harsh conditions without compromising on functionality or reliability.
It operates within an extensive temperature range, making it suitable for various industrial applications worldwide. With support for multiple communication protocols, the IS239TRLYH1B ensures compatibility with a wide array of equipment, enhancing system integration and data exchange capabilities. This facilitates efficient management and monitoring of industrial processes. Featuring an optimized power consumption profile, the PCB is energy-efficient, contributing to reduced operational costs and environmental impact. Its compact size and lightweight construction make it easy to install and maintain in tight spaces.
Our team of experts is dedicated to providing exceptional customer service and technical support. Should you encounter any issues or require assistance during installation or operation, we are here to assist you. Your satisfaction is our top priority. The GE IS239TRLYH1B Industrial Printed Circuit Board is designed for advanced industrial control applications, featuring high reliability and robust performance in harsh environments.
Features
▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user memory.
▪ Provides access to bulk memory via reference table %W.
▪ Configurable data and program memory.
▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.
▪ Supports auto-located Symbolic Variables that can use any amount of user memory.
▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for analog %AI and %AQ.
▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.
▪ Supports all VME modules supported by Series 90-70.
▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server and FTP connections.
▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.
▪ Test Edit mode allows you to easily test modifications to a running program.
▪ Bit-in-word referencing.
▪ Battery-backed calendar clock.
▪ In-system upgradeable firmware.
▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232 Ethernet station manager serial port.
▪ The embedded Ethernet interface provides:
- Data exchange using Ethernet Global Data (EGD)
- TCP/IP communication services using SRTP
- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client
- Full programming and configuration services
- Comprehensive station management and diagnostic tools
- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network switch providing auto-negotiated network speed, duplex mode, and crossover detection.
- User-configurable Redundant IP address
- Time synchronization to SNTP time server on Ethernet network (when used with Release 5.00 or later CPU module).
