ABB P-HC-PLT-10111100 Harmony NCC Coupler Unit
❤ Add to collection

ABB P-HC-PLT-10111100 Harmony NCC Coupler Unit

+86-15305925923
Mr.Wang
wang@kongjiangauto.com
P-HC-PLT-10111100 Harmony NCC Coupler Unit
12060.00
¥7373.00
Weight:2.000KG
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description
P-HC-PLT-10111100 Harmony NCC Coupler Unit

ABB P-HC-PLT-10111100 Harmony NCC Coupler Unit

Basic Information

Model No.: P-HC-PLT-10111100.

Name: Harmony NCC Coupler Unit, that is, Harmony Network Control Centre Coupler Unit, is used to achieve the Harmony system between different nodes or devices coupling connection and data communication key components.

Series: belongs to ABB Bailey Infi 90 series, which is widely used in industrial automation control system.

Hardware performance

Processor and Memory: A Power PC processor with 32MB of RAM is used to efficiently process the data and control tasks in the system to meet the complex control needs of industrial sites.

Physical Size and Weight: Measuring approximately 13.0 inches by 6.0 inches by 10.0 inches (33.0 cm by 15.2 cm by 25.4 cm) and weighing approximately 8 pounds, 8 ounces (3.9 kg), the compact dimensions and moderate weight make it easy to install and lay out in control cabinets or equipment rooms.

Communication Capabilities

Cnet network: Support standard Cnet communication, high-speed and reliable data interaction with other system nodes through the Cnet network, to achieve centralised management and distributed control of the system, to ensure the coordinated operation of all parts of the system.

Internal communication: With Intra Comm Int internal communication interface, it is used for the communication between different modules or components within Harmony NCC Coupler Unit, which guarantees the fast and accurate data transmission within the unit and improves the overall performance and response speed of the system.

Functional Features

Coupling and Connection Function: As a coupling unit, it can connect devices, nodes or sub-systems in multiple Harmony systems together to achieve data sharing and collaborative work between different parts, so that the whole system can operate as an organic whole and enhance the system's integrity and functionality.

Data processing and forwarding: It is responsible for processing, converting and forwarding the data transmitted between the connected devices to ensure the accuracy and consistency of the data, and can adapt to the differences in data formats and communication protocols between different devices to achieve seamless data interaction.

System Expansion and Integration: Convenient for system expansion and upgrading, when it is necessary to add new devices or functional modules, the coupling unit can be easily integrated with the existing system, without the need to carry out large-scale reconstruction and reconfiguration of the entire system, reducing the cost and difficulty of system upgrading.

Reliability and stability: the use of high-quality electronic components and advanced manufacturing process, has a high degree of reliability and stability, can be in the harsh industrial environment, long-term stable operation, reduce the system downtime due to equipment failure, improve production efficiency.

Application Fields

Mainly used in chemical, electric power, metallurgy, petroleum and other industries in the automation control system, for large-scale industrial production process equipment monitoring, data acquisition, process control and other reliable communication and coupling solutions to ensure that the production process of safe, stable and efficient operation.
