ABB Fan Module RMF 51 H&B Contronic
❤ Add to collection

ABB Fan Module RMF 51 H&B Contronic

+86-15305925923
Mr.Wang
wang@kongjiangauto.com
Fan Module RMF 51 H&B Contronic
5706.00
¥1436.00
Weight:2.000KG
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description
Fan Module RMF 51 H&B Contronic

ABB Fan Module RMF 51 H&B Contronic

Functional Features

Efficient Heat Dissipation: It is specially designed to provide efficient heat dissipation for industrial equipment to ensure that the equipment operates within the normal temperature range and prevent equipment failure and performance degradation due to overheating. For example, in some large industrial automation control cabinets, it can continuously dissipate heat for various electronic components such as PLCs, power modules, drives, etc. in the control cabinet to maintain stable operation of the equipment.

Intelligent control: with intelligent control function, it can automatically adjust the speed of the fan according to the temperature of the equipment. When the temperature of the equipment is low, the fan runs at a lower speed to reduce energy consumption and noise; when the temperature of the equipment rises, the fan automatically accelerates the speed to enhance the cooling effect. This intelligent speed control function not only extends the service life of the fan, but also effectively saves energy.

Multiple Protection Mechanisms: It has multiple protection functions, such as overcurrent protection, overheating protection, overload protection, and so on. When there is an abnormal situation of the fan, such as excessive current, high temperature or overload, the module will automatically take corresponding protective measures, such as cutting off the power supply or reducing the speed of the fan, in order to avoid damage to the fan and other equipment.

Strong compatibility: With good compatibility with other ABB H&B Contronic series modules, it can be easily integrated into the existing industrial automation control system and work with other modules to achieve overall optimization and efficient operation of the system.

Technical Parameters

Power supply voltage: The standard industrial power supply voltage of 24V DC or 230V AC is usually adopted to adapt to different industrial application scenarios. Under the voltage fluctuation range of ±10%, it can still work stably to ensure the normal operation of the fan module.

Fan speed: The fan speed can be adjusted according to the actual demand, generally the highest speed can be up to thousands of revolutions per minute, which can provide enough airflow to meet the cooling needs of different equipment. For example, in some high power inverters or motor drives, a higher fan speed is needed to dissipate heat quickly.

Air volume and air pressure: with large air volume and air pressure output capacity, the air volume is usually between tens and hundreds of cubic meters per hour, and the air pressure can reach several hundred Pascals, which can effectively overcome the air resistance inside the equipment, and discharges the heat quickly.

Noise level: During normal operation, the noise level of the fan module is relatively low, generally below 50 dB, which will not cause significant noise pollution to the working environment.

Protection level: High protection level, such as IP54 or higher, can effectively prevent dust and moisture from entering the module, and adapt to the harsh industrial environment.

Applications

Industrial automation control system: Widely used in a variety of industrial automation equipment, such as PLC control cabinets, frequency converters, servo drives, industrial computers and so on. Provide reliable heat dissipation for these devices to ensure the long-term stable operation of the equipment. For example, in the automated production line of an automobile manufacturing plant, a large number of PLCs and drives need to use the fan module for heat dissipation.

Power electronic equipment: There are also important applications in power electronic equipment such as inverters, rectifiers, uninterruptible power supplies (UPS) and so on. These devices generate a lot of heat during operation and require an efficient cooling system to maintain normal operation. the RMF 51 fan module automatically adjusts the fan speed according to the heat changes in the device, realizing energy-saving heat dissipation.

Communication equipment: In communication base stations, server rooms and other communication equipment, it is used to dissipate heat for communication equipment such as switches, routers, servers and so on. Ensure that the communication equipment can still work normally in a high temperature environment, and improve the reliability and stability of the communication system.

Installation and Maintenance

Installation: The installation methods are flexible and varied, such as rail mounting, panel mounting or fixing directly inside the equipment. The installation process is simple and convenient, and users can choose the appropriate installation method according to the actual situation. During installation, attention should be paid to ensure that the connection between the fan module and the equipment is tight to avoid loosening due to vibration.

Maintenance points: Regularly clean and inspect the fan module, remove dust and debris on the fan blades and radiator to ensure good ventilation. At the same time, check the operation of the fan, if you find abnormal rotation or abnormal noise, it should be repaired or replaced in time. It is generally recommended to conduct a comprehensive maintenance check every 3-6 months.
