ABB Battery Module AM801F
❤ Add to collection

ABB Battery Module AM801F

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

Features

… ARM-CPU with integrated Ethernet controller, 32-bit data

bus, 32-bit address bus

… Flash EPROM for module CPU and protocol software.

… Software/firmware update without EPROM exchange.

… Separate memory for module CPU.

… Shared memory for data exchange between main proces sor and module CPU. Data protection by parity check.

… Automatic detection if 10BaseT or 100BaseTX is con nected.


￥14500.00
￥15000.00
Weight：3.500KG
Quantity：
(Inventory: 30)
Consultation
Accessories
  • Bently-3500/42M-
    Original ：￥18327.00
    With a price ：￥18327    		 Quantity
  • ABB-3BSE020269R0
    Original ：￥16364.00
    With a price ：￥16364    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

Features

… ARM-CPU with integrated Ethernet controller, 32-bit data

bus, 32-bit address bus

… Flash EPROM for module CPU and protocol software.

… Software/firmware update without EPROM exchange.

… Separate memory for module CPU.

… Shared memory for data exchange between main proces sor and module CPU. Data protection by parity check.

… Automatic detection if 10BaseT or 100BaseTX is con nected.




ABB Battery Module AM801F

Features
… Provides battery backup for PM802F only
… Enables redundant battery energy backup on the AC 800F
Description
The battery module provides for retention of the AC 800F RAM
data when the AC 800F is off or has no Ethernet module.
The battery module is used when the AC 800F is used as a
stand-alone device, i.e. when it has no Ethernet connection, or
when the only existing Ethernet module is to be replaced without the AC 800F loosing its configuration data.
LED Displays
State
Off No supply power, module is isolated
Green Power supply on, module identified and
ready to operate as configured.
Orange Power supply on, module identified and
either:
— normal transitory state after module
startup
— configuration mode of Boot Loader
Red Module power supply is on and either:
— module not yet identified (normal for
short time, during module startup)
— error occurred during module test
Batt Low
Off Sufficient buffer battery voltage.
Orange Buffer battery not found or low (insufficient voltage).
Technical Data
Rated voltage 3.3 V / 5 V, ±3%, from CPU board
Power consumption approx. 0.25 W
Page 20 June 2006
Battery 3.6 V lithium battery, 950 mAh
(included in delivery)
Low battery
signaling ≤ 2.4 V
RAM and real-time-clock buffering time
New battery inserted ≥ 1,5 years
After “Low” warning ≥ 10 days
Weight approx. 0.150 kg without buffer battery
approx. 0.170 kg with buffer battery


Features
… Provides battery backup
… Enables redundant battery energy backup on the AC 800F
Description
The battery module provides for retention of the AC 800F RAM
data when the AC 800F is off or has no Ethernet module.
The battery module is used when the AC 800F is used as a
stand-alone device, i.e. when it has no Ethernet connection, or
when the only existing Ethernet module is to be replaced with out the AC 800F loosing its configuration data.
LED Displays
State
Off No supply power, module is isolated
Green Power supply on, module identified and
ready to operate as configured.
Orange Power supply on, module identified and ei ther:
— normal transitory state after module
startup
— configuration mode of Boot Loader
Red Module power supply is on and either:
— module not yet identified (normal for
short time, during module startup)
— error occurred during module test
Battery (PM803F)
Off AC 800F is active, AM 811F not active
=>buffering from power supply module
AC 800F is off (no watchdog of the batter ies voltage) =>buffering from battery.
Orange During battery recovery or start-up phase
Red Warning: battery low, no battery inserted,
insufficient electrical contact etc.

Green battery inserted and data protection pro vided.
Battery (PM802F)
Off Sufficient buffer battery voltage
Orange Buffer battery not found or low (insufficient
voltage).

Technical Data
Rated voltage 3.3 V / 5 V, ±3%, from CPU board
Power consumption approx. 0.28 W
Battery 3.6 V lithium battery, 950 mAh
(included in delivery)
Low battery
signaling ≤ 3.2 V
RAM and real-time-clock buffering time
PM 803F PM 802F
New battery inserted ≥ 10 days ≥ 1,5 years
After “Low” warning ≥ 5 hours ≥ 10 days
Weight approx. 0.150 kg without buffer battery
approx. 0.170 kg with buffer battery
