GE DS3800HCMB1C1C Universal Communication Processor, Designed for Precision Control in Industrial Automation

GE DS3800HCMB1C1C  Universal Communication Processor, Designed for Precision Control in Industrial Automation

Model:DS3800HCMB1C1C Category:GE Boards & Turbine Control / Mark IV DS3800 Processor Type:Universal Operating Temperature Range:-40"C to +85"C Memory Capacity:Up to 1 MB Communication Interfaces:RS-485, Ethernet Power Consumption:6 W (typical) Integrating cutting-edge technology, the GE DS3800HCMB1C1C Universal Communication Processor Module is specifically engineered to enhance operational efficiency and reliability in complex industrial environments.

 This module boasts an ultra-efficient processor, designed to handle high-speed data processing tasks with ease, ensuring smooth communication between various control systems and devices. Operable within a wide temperature range, from -40"C to +70"C, it ensures consistent performance under extreme conditions, making it ideal for harsh industrial settings. Featuring versatile communication interfaces such as RS-485 and Ethernet, this module facilitates seamless integration with a wide array of industrial protocols, enabling seamless data exchange across different systems.

 With its substantial memory capacity, the DS3800HCMB1C1C can store extensive amounts of operational data, providing valuable insights for predictive maintenance and process optimization. Compact yet powerful, this module is designed to fit into tight spaces without compromising on performance, making it a perfect solution for space-constrained industrial applications. The GE DS3800HCMB1C1C is a high-performance Universal Communication Processor Module designed for seamless integration in industrial control systems, offering robust data processing capabilities.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
