GE DS511A (P/N:199-19401) Asynchronous Data Set

GE DS511A (P/N:199-19401) Asynchronous Data Set

Type:Asynchronous Data Set Model Number:DS511A Power Supply:12V DC Communication Protocol:RS-485 Data Rate:Up to 1 Mbps Operating Temperature:-20"C to +60"C Relative Humidity:5% to 95% non-condensing Dimensions:200mm x 100mm x 25mm Weight:0.2kg Connectors:DB-9 female connector Introducing the GE DS511A Asynchronous Data Set, a critical component for industrial automation systems. This device ensures reliable and efficient data exchange, crucial for the smooth operation of complex process control environments. Featuring a robust design and advanced communication protocol support, the DS511A enables seamless integration with a wide range of devices and systems, ensuring compatibility and flexibility across diverse industrial settings. With a data rate capability up to 1 Mbps and an operating temperature range from -40"C to +85"C, this asynchronous data set is engineered to withstand harsh environmental conditions without compromising performance.

 It  an ideal choice for applications requiring robust data transmission in challenging climates or industrial settings. The low power consumption of less than 1W makes it energy-efficient, reducing operational costs while maintaining high reliability. Its compact size (2.5in x 2.5in x 1.3in) allows for easy installation and integration into existing control systems without space. Equipped with a single RJ-45 connector for device connectivity, the DS511A simplifies setup and configuration processes, minimizing downtime and enhancing overall system efficiency. This makes it a preferred solution for engineers and technicians seeking to optimize their industrial networks. The GE DS511A Asynchronous Data Set is designed for seamless data transfer in industrial automation environments, ensuring high reliability and efficiency in communication systems.

Compatibility

ƒ Compatible with any Series 90-30 CPU except IC693CPU321 and IC693CPU340. Configuration size is limited for CPU311/313/331, as described on the next page.

ƒ Requires release 8.0 CPU firmware. The latest Release 10 is recommended, if available for the particular CPU.

ƒ Requires CIMPLICITY Machine Edition Logic Developer PLC version 3.0 plus the appropriate service pack or special (or a version later than 3.0).

ƒ Not compatible with the VersaPro™, Control, or Logicmaster™ programming software.

ƒ The Series 90-30 Hand-Held Programmer (IC693PRG300) cannot be used to configure this module. New Features The Series 90-30 DeviceNet Master Module allows a Series 90-30 PLC to send and receive I/O data from a DeviceNet network.

Module features include:

ƒ Support for all standard data rates (125K, 250K, 500K)

ƒ Support for 255 bytes input data transfer and 255 bytes output data transfer per slave

ƒ Support for 3972 bytes of input data transfer and 3972 bytes of output data transfer per master

ƒ Support for two I/O connections per Slave - Typically one connection is used for Polled and the other is used for Strobe, Cyclic, or COS

ƒ Support for Poll, Strobe, Cyclic and COS I/O Connections, Fragmented I/O and Explicit Messaging

ƒ Support for Unconnected Message Manager (UCMM) with 1 proxy connection per slave device

ƒ Support for configuration of the global scan rate

ƒ Support for configuration of update rates for Poll and COS/Cyclic on a connection basis

ƒ Support for PLC-application initiated explicit messaging via a COMMREQ

ƒ Master can be configured to operate as a slave simultaneously with master operation

ƒ Configurable fault behavior on loss of communication

ƒ Reports loss or reestablishment of communication with slaves in PLC fault table (configurable)

ƒ Support for 64 network device status bits (note: the bit for the master itself is always zero)

ƒ Firmware update via service port on module
