Benefits

Increases productivity

The MQ Controller is as quick as the MD Plus Controller and provides the same configurable memory as the MD Plus controller, while Enhanced Memory handling got added.The Ethernet ports are full duplex, 100MB/second maximum throughput. The results are lower CPU utilization and higher capacity for control strategies.

Self-addressing.

The DeltaV controller is unique in its ability to automatically identify itself to the DeltaV control network. When the controller is powered up, it is automatically assigned a unique address—no dip switches, no configuring—just plug and play!

Self-locating.

 A controller’s physical location is easy to find. LEDs on the face of the controller can be made to flash, providing a strong visual clue.

Easy to use

Total control. The controller manages all control activities for the I/O interface channels. It also manages all communication functions for the communications network. Time tamping, alarming, and trend objects are also managed within the controller. The controller executes all control strategy with execution speeds up to every 100 ms.

Data protection.

All online changes made to control parameters are automatically stored for later upload into the engineering database. This way, the system always retains a complete record of all the data that has been changed online.

Cold restart.

This feature provides automatic restart of the controller in case of a power failure. The restart is completely autonomous because the entire control strategy is stored in NVM RAM of the controller for this purpose. Simply set the restart state of the controller to current conditions.

Data pass-through.

The controller is equipped with the ability to pass smart HART information from field devices to any workstation node in the control network. This means you can take advantage of applications, such as Asset Management Solutions, that enable you to remotely manage the HART information contained in your HART or FOUNDATION fieldbus-equipped devices.

Prepares you for the future.

As your system grows, you can expand your software license to increase the number of device signal tags (DSTs) allocated to the DeltaV controller. Begin with 50 and expand to 750 DSTs. Control strategy complexity and control module scan rates determine overall controller performance and application size. A redundant controller may be added to back up an MQ Controller online. The standby controller comes online automatically, with a bumpless transition. For more information, refer to the I/O Redundancy product data sheet.

Specifications

Power, Mounting, and Memory

Power requirement:Supplied by System Power Supply through 2-wide Power/Controller Carrier

Fuse protection:3.0 A, non-replaceable fuses

Power dissipation:5.0 W typical, 7.0 W maximum

Mounting:On right slot of power/controller carrier.

Primary Control Network:8-pin RJ-45 connector

LED Indicators (ON Status)

Green – Power:Indicates DC power is applied.

Red – Error:Indicates an error condition.

Green – Active:Indicates that the controller is operating as the primary controller.

Green – Standby:Indicates that the controller is operating as a backup controller (reserved for future use).

Yellow flashing – Pri. CN:Indicates valid primary control network communication.

Environmental

Operating temperature:-40° to 70° C (-40° to 158° F)

Storage temperature:-40° to 85° C (-40° to 185° F)

Relative humidity:5 to 95%, non-condensing

Airborne contaminants:ISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating

Shock (normal operating conditions):10 g ½-sine wave for 11 ms
