FOXBORO FCM10E Fieldbus Communications Module

FOXBORO  FCM10E Fieldbus Communications Module

DESCRIPTION

The FCM10E Fieldbus Communications Module is a communications interface which allows the DIN rail mounted Fieldbus Modules (FBMs) to communicate with I/A Series control stations via the high speed, optionally redundant 10 Mbps Ethernet trunk Fieldbus . The FCM10E converts 10 Mbps Ethernet signals used by the control station to 2 Mbps signals used by the FBMs, and vice versa. They also provide galvanic isolation between the 10 Mbps Ethernet trunk Fieldbus and the 2 Mbps module Fieldbus.

The FCM10E modules are used in pairs for redundancy. An FCM10E (or pair of FCM10E modules) can support up to 30 FBMs.FCM10E modules have a compact design, with a rugged extruded aluminum exterior for physical protection of the circuits. Up to 30 FCM10E pairs can be connected to the Ethernet trunk Fieldbus. Enclosures specially designed for mounting of DIN rail mounted FBM equipment provide various levels of environmental protection for the Fieldbus Communications Modules, up to harsh environments per ISA Standard S71.04.

BASEPLATE MODULE MOUNTING

The FCM10E mounts on a baseplate, which is either DIN rail mounted or rack mounted and includes signal connectors for Fieldbus, power, and I/O cable connections. A baseplate can support up to eight FBMs, or a combination of FBMs and FCMs.

FUNCTIONAL SPECIFICATIONS

Power Requirements

INPUT VOLTAGE RANGE (REDUNDANT) 24 V dc +5%, -10%

CONSUMPTION 7 W (maximum) at 24 V dc

HEAT DISSIPATION 7 W (maximum) at 24 V dc

Vibration 0.75 g (5 to 200 Hz)

Calibration Requirements Calibration of the module is not required.

ENVIRONMENTAL SPECIFICATIONS

TEMPERATURE -20 to +70°C (-4 to +158°F)

RELATIVE HUMIDITY 5 to 95% (noncondensing)

ALTITUDE -300 to +3,000 m (-1,000 to +10,000 ft)

Storage TEMPERATURE -40 to +70°C (-40 to +158°F)

RELATIVE HUMIDITY 5 to 95% (noncondensing)

ALTITUDE -300 to +12,000 m (-1,000 to +40,000 ft)

Dimensions

HEIGHT 102 mm (4 in) 114 mm (4.5 in) including mounting lugs

WIDTH 45 mm (1.75 in)

DEPTH 104 mm (4.11 in)

APPLICATIONS

• Simulation

• Instrumentation

• Industrial control

• Process control and monitoring

• Factory automation

• Intelligent networked PLC controllers

• Automated test

• Data acquisition
